Trade & Volume Pricing Available
Bohler Flux Cored Wire - BOHLER Ti 52T-FD FCAW 1.6mm 15Kg
Flux-cored wire, seamless, unalloyed, rutile type Classification: E71-T1C/T1M-H4
Seamless rutile flux cored wire for single- or multilayer welding of Carbon, Carbon-Manganese steels and similar types of steels including fine grain steels with Argon-CO2 shielding gas or pure CO2.
Main features: excellent weldability in all positions with high performance welding speed, very low spatter losses, good bead appearance, fast freezing and easy to remove slag.
This wire is especially suitable for ship building, structural steel work or wherever good bead appearance is required. D1.8 Seismic Supplement approved.
This product can be used in sour gas applications. (HIC tested acc. to NACE TM-0284).
Test values for SSC are available upon request. Typical hydrogen value 2.5 – 3.5ml/100g weld metal.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - BOHLER Ti 60T-FD FCAW 1.6mm 15Kg
Flux-cored wire, seamless, high strength, rutile type
Classification: E81T-Ni1 M-H4Seamless rutile, Nickel alloyed, flux-cored wire for single- or multilayer welding of Carbon, CarbonManganese steels and high strength steels with Argon-CO2.
Main features: excellent weldability in all positions, excellent bead appearance, very low spatter losses, fast freezing and easy to remove slag.
The exceptional mechanical properties of this wire even at low temperatures (-60°C), also after post-weld heat treatment make it especially suitable for offshore applications.
The wire is CTOD tested at -10°C. (14°F) This product can be used in sour gas applications. (HIC tested acc. to NACE TM-0284).
Test values for SSC are available upon request.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - BOHLER Ti 71-TIC FCAW 1.6mm 15Kg
Flux-cored wire
Classification: E71-T1C -H8BOHLER Ti 71-T1C is a rutile flux cored wire with fast freezing slag. Excellent welding characteristics in all positions, using 100% CO2 gas.
Very good mechanical properties, easy slag removability, low spatter level, smooth and well-shaped beads with X-ray-quality.
Applicable in out of position welding, with higher productivity and less time for post weld cleaning.
Suitable for butt and fillet welding of hulls, storage tanks, mechanical and constructional steel structure and bridge.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - BOHLER Ti 81 Ni TIC FCAW 1.6mm 15Kg
Flux Cored Wire
Classification: E81T1-Ni1C-H8BOHLER Ti 81Ni-T1C is a rutile flux cored wire and designed for all-position welding with excellent CVN impact properties in as welded condition at - 40°C.
Excellent welding characteristics in all positions.
Very good mechanical properties, easy slag removability, low spatter level, smooth and good weld beads with X-ray-quality.
Applicable in out-of-position welding, with higher productivity and less time for postweld cleaning. Applicable for Single pass & multi passes weld.
Suitable for Butt, fillet welding of 490N/mm2 class high strength steel and low temperature steel of structure such as ships, bridges, buildings and storage tanks etc..
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - BOHLER Ti 52 T-FD FCAW 1.6mm 15Kg
Flux-cored wire, seamless, unalloyed, rutile type Classification: E71-T1C/T1M-H4
Seamless rutile flux cored wire for single- or multilayer welding of Carbon, Carbon-Manganese steels and similar types of steels including fine grain steels with Argon-CO2 shielding gas or pure CO2.
Main features: excellent weldability in all positions with high performance welding speed, very low spatter losses, good bead appearance, fast freezing and easy to remove slag.
This wire is especially suitable for ship building, structural steel work or wherever good bead appearance is required. D1.8 Seismic Supplement approved.
This product can be used in sour gas applications. (HIC tested acc. to NACE TM-0284).
Test values for SSC are available upon request. Typical hydrogen value 2.5 – 3.5ml/100g weld metal.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - BOHLER Ti 60 T-FD FCAW 1.6mm 15Kg
Flux-cored wire, seamless, high strength, rutile type Classification: E81T-Ni1 M-H4
Seamless rutile, Nickel alloyed, flux-cored wire for single- or multilayer welding of Carbon, CarbonManganese steels and high strength steels with Argon-CO2.
Main features: excellent weldability in all positions, excellent bead appearance, very low spatter losses, fast freezing and easy to remove slag.
The exceptional mechanical properties of this wire even at low temperatures (-60°C), also after post-weld heat treatment make it especially suitable for offshore applications.
The wire is CTOD tested at -10°C. (14°F) This product can be used in sour gas applications. (HIC tested acc. to NACE TM-0284).
Test values for SSC are available upon request.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - BOHLER Ti 71-TIC FCAW 1.6mm 15Kg
Flux-cored wire
Classification: E71-T1C -H8BOHLER Ti 71-T1C is a rutile flux cored wire with fast freezing slag.
Excellent welding characteristics in all positions, using 100% CO2 gas. Very good mechanical properties, easy slag removability, low spatter level, smooth and well-shaped beads with X-ray-quality.
Applicable in out of position welding, with higher productivity and less time for post weld cleaning.
Suitable for butt and fillet welding of hulls, storage tanks, mechanical and constructional steel structure and bridge.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - BOHLER Ti 81 Ni-T1C FCAW 1.6mm 15Kg
Flux Cored Wire
Classification: E81T1-Ni1C-H8BOHLER Ti 81Ni-T1C is a rutile flux cored wire and designed for all-position welding with excellent CVN impact properties in as welded condition at - 40°C.
Excellent welding characteristics in all positions.
Very good mechanical properties, easy slag removability, low spatter level, smooth and good weld beads with X-ray-quality. Applicable in out-of-position welding, with higher productivity and less time for post weld cleaning.
Applicable for Single pass & multi passes weld.
Suitable for Butt, fillet welding of 490N/mm2 class high strength steel and low temperature steel of structure such as ships, bridges, buildings and storage tanks etc..
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler Flux Cored - Avesta FCW 2507/P100-PW NOR 1.2mm 15Kg
Flux-cored wire, high-alloyed, super duplex stainless
Classification: E2594T1/4
Rutile flux-cored wire of T 25 9 4 N LP / E2594T1 type designed for welding ferritic-austenitic super duplex steel and equivalent steel grades such as 1.4410 / UNS S32570 and 1.4501 / UNS S32760.
Can also be used for joints between super duplex grades and austenitic stainless steels or carbon steels. Super duplex steels are particularly popular for desalination, pulp & paper, flue gas desulphurization and seawater systems.
Developed to fulfil severe requirements, such as those in NORSOK M-601 and similar standards. Properties of the weld metal match those of the parent metal, offering high tensile strength and toughness as well as excellent resistance to stress corrosion cracking and localized corrosion in chloride-containing environments.
Meet the corrosion test requirements per ASTM G 48 Methods A, B and E (40°C). Overalloyed in nickel to promote austenite formation. Ferrite measured with FeritScope FMP30 45 – 51 FN. Designed for all-round welding and can be used in all positions without changing the parameter settings.
The weldability is excellent in the vertical-up and overhead welding positions. The operating temperature range is –50°C to 220°C.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - Avesta FCW 2205-PW 1.2mm 15Kg
Flux-cored wire, high-alloyed, duplex stainless
Classification: E2209LT-1-4Rutile flux-cored wire of T 22 9 3 N L P / E2209T1 type. Primarily designed for welding 22Cr duplex stainless steels such as 1.4462 / UNS S32205 and S31803 used in offshore, shipyards, chemical tankers, chemical/ petrochemical, pulp & paper, etc. Avesta FCW 2205-PW (FOXcore 2209-T1) has a stronger arc and a faster slag compared to Avesta FCW-2D 2205 (FOXcore 2209-T0).
It is designed for all-round welding and can be used in all positions without changing the parameter settings. The weldability is excellent in the vertical-up and overhead welding positions.
Very good resistance to pitting and stress corrosion cracking in chloride-containing environments. Meets the corrosion test requirements per ASTM G48 Methods A, B and E (25°C).
Over-alloyed in nickel to promote austenite formation. Ferrite measured with FeritScope FMP30 35 – 41 FN.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - Avesta FCW309L-PW 1.2mm 15Kg
Flux-cored wire, high-alloyed, austenitic stainless, special applications
Classification: E309LT-1-4Austenitic stainless steel flux-cored wire of T 23 12 L P / E309LT1 type, primarily intended for surfacing low-alloyed steels and for dissimilar welds between mild steel and stainless steels.
Ferrite measured with FeritScope FMP30 14 – 22 FN. Corrosion resistance superior to T 19 9 L / E308L fillers. When used for overlay welding on mild steel a corrosion resistance equivalent to that of 1.4301 / 304 is obtained already in the first layer.
Avesta FCW 309L-PW (FOXcore 309L-T1) has a stronger arc and a faster freezing slag compared Avesta FCW-2D 309L (FOXcore 309L-T0 DG). It is designed for all-round welding and can be used in all positions without changing the parameter settings.
Very good slag detachability and almost no spatter formation. Due to the fast freezing rutile slag, the weldability is excellent also in the vertical up and overhead positions.
Maximum application temperature 300°C. The scaling temperature is approximately 1000°C in air.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - Avesta FCW316L/SKR-PW 1.2mm 15Kg
Flux-cored wire, high-alloyed, austenitic stainless
Classification: E316LT-1/4Rutile flux-cored wire of T 19 12 3 L P / E316LT1 type designed for welding 1.4404, 1.4432 / 316L type stainless steels with excellent resistance to general, pitting and intergranular corrosion in chloride-containing environments.
Intended for severe service conditions, e.g. in dilute hot acids. Also suitable for welding steels that are stabilized with titanium or niobium, such as 1.4571 / 316Ti for service temperatures not exceeding 400°C.
For higher temperatures, a niobium-stabilized consumable such as BÖHLER SAS 4 PW-FD (FOXcore 318-T1) is required. The scaling temperature is approximately 850°C in air.
Avesta FCW 316L/SKR-PW has a stronger arc and a faster freezing slag as compared to Avesta FCW-2D 316L/SKR (FOXcore 316L-T0 DG). It is designed for all-round welding and can be used in all positions without changing the parameter settings.
Very good slag detachability and almost no spatter formation. Due to the fast freezing rutile slag, the weldability is excellent also in the vertical up and overhead positions.
For flat and horizontal welding positions, Avesta FCW-2D 316L/SKR (FOXcore 316L-T0 DG) may be preferred.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - Avesta FCW308L/MVR-PW 1.2mm 15Kg
Flux-cored wire, high-alloyed, austenitic stainless
Classification: E308LT1-4Rutile flux-cored wire of T 19 9 L P / E308LT1 type designed for welding 1.4307 / 304L type stainless steels with good corrosion resistance under fairly severe conditions, e.g. in oxidizing acids and cold or dilute reducing acids.
Also suitable for welding steels that are stabilized with titanium or niobium, such as 1.4541 / 321, 1.4878 / 321H and 1.4550 / 347 in cases where the construction will be operating at temperatures below 400°C. For higher temperatures, a niobium-stabilized wire such as BÖHLER SAS 2 PW-FD (FOXcore 347- T1) is required.
The scaling temperature is approximately 850°C in air.
Avesta FCW 308L/MVR-PW has a stronger arc and a faster freezing slag compared to Avesta FCW-2D 308L/MVR (FOXcore 308L-T0 DG).
It is designed for all-round welding and can be used in all positions without changing the parameter settings. Very good slag detachability and almost no spatter formation.
Due to the fast freezing rutile slag, the weldability is excellent also in the vertical up and overhead positions.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - Avesta FC 316L T1 FCAW 1.2mm 15Kg
Flux-cored wire, high-alloyed, austenitic stainless
Classification: E316LT1-1Avesta FC 316L-T1 is designed for welding austenitic stainless steel type 17Cr 12Ni 2.5Mo or similar.
This filler metal is also suitable for welding titanium and niobium stabilised steels such as ASTM 316Ti in case where the construction will be operating at temperatures below 400oC.
For higher temperatures, niobium stabilised consumable such as Avesta 347/MVNb is required.
Avesta FC 316L-T1 provides excellent usability with stable arc, less spattering, good bead appearance, better slag removal, and it is designed for all-round welding and can be used in all positions without changing parameter settings.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - Avesta FC 309L T1 FCAW 1.2mm 15Kg
Flux-cored wire, high-alloyed, austenitic stainless, special applications
Classification: E309LT1-1Avesta FC 309L-T1 is a high-alloy 23Cr 13Ni wire primarily intended for surfacing on low-alloy steels and for dissimilar welds between mild steel and stainless steel.
It provides excellent usability with stable arc, less spattering, good bead appearance, and better slag removal.
Avesta FC 309L-T1 is designed for all-round welding and can be used in all positions without changing parameter settings.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - Avesta FC 308L T1 FCAW 1.2mm 15Kg
Flux-cored wire, high-alloyed, austenitic stainless
Classification: E308LT1-1Avesta FC 308L-T1 is designed for welding austenitic stainless steel type 19Cr 10Ni or similar.
This filler metal is also suitable for welding titanium and niobium stabilised steels such as ASTM 321 and ASTM 347 in case where the construction will be operating at temperatures below 400oC.
For higher temperatures, niobium stabilised consumable such as Avesta 347/MVNb is required.
Avesta FC 308L-T1 provides excellent usability with stable arc, less spattering, good bead appearance, better slag removal, and it is designed for all-round welding and can be used in all positions without changing parameter settings.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - Diamondspark X70 RC-Pipe FCAW 1.2mm 15Kg
Flux cored wire, seamless, for automatic pipeline welding, rutile type - Classification: E91T-1 M H4
Seamless rutile, Nickel-Manganese alloyed, flux cored wire for single- or multilayer welding of carbon, carbon-manganese steels and high strength steels with Ar-CO2 shielding gas.
Main features: excellent weldability in all positions, excellent bead appearance, very low spatter losses, fast freezing and easy to remove slag.
The exceptional mechanical properties of this wire even at low temperatures as well as the low content of diffusible hydrogen make it especially suitable for pipeline applications.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - Foxcore 308L-T1 FCAW 1.2mm 15Kg
Flux-cored wire, high-alloyed, austenitic stainless
Classification: E308LT1-4Rutile flux-cored wire of T 19 9 L P / E308LT1 type designed for welding 1.4307 / 304L type stainless steels with good corrosion resistance under moderately severe conditions, e.g. in oxidizing acids and cold or dilute reducing acids.
Also suitable for welding steels that are stabilised with titanium or niobium, such as 1.4541 / 321, 1.4878 / 321H and 1.4550 / 347, but for service temperatures above 350°C, a niobium-stabilised wire such as FOXcore 347-T1 would be required. The scaling temperature is approximately 850°C in air. FOXcore 308L-T1 has a stronger arc and a faster freezing slag compared to FOXcore 308L-T0 DG.
It is designed for all-round welding and can be used in all positions without changing the parameter settings.
Very good slag detachability and almost no spatter formation. Due to the fast freezing rutile slag, the weldability is excellent also in the vertical up and overhead positions.
The wide arc ensures even penetration and side-wall fusion to prevent lack of fusion.
Suitable for service temperatures from –196°C to 350°C. For flat and horizontal welding positions, FOXcore 308L-T0 or FOXcore 308L-T0 DG may be preferred.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - Foxcore 309L-T1 FCAW 1.2mm 15Kg
Flux-cored wire, high-alloyed, austenitic stainless, special applications
Classification: E309LT1-4Rutile flux-cored wire of T 23 12 L P / E309LT1 type, primarily intended for surfacing low-alloyed steels and for dissimilar welds between mild steel and stainless steels. Ferrite measured with FeritScope FMP30 14 – 22 FN.
Corrosion resistance superior to T 19 9 L / E308L fillers. When used for overlay welding on mild steel a corrosion resistance equivalent to that of 1.4301 / 304 is obtained already in the first layer. FOXcore 309LT1 has a stronger arc and a faster freezing slag compared to FOXcore 309L-T0 DG.
The wide arc ensures even penetration and side-wall fusion to prevent lack of fusion.
It is designed for all-round welding and can be used in all positions without changing the parameter settings.
Due to the fast freezing rutile slag, the weldability is excellent also in the vertical-up and overhead positions.
Very good slag detachability and almost no spatter formation. Suitable for service temperatures from –60°C to 300°C. The scaling temperature is approximately 1000°C in air.
For flat and horizontal welding positions, FOXcore 309L-T0 DG may be preferred.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - Foxcore 316L-T1 FCAW 1.2mm 15Kg
Flux-cored wire, high-alloyed, austenitic stainless
Classification: E316LT1-4Rutile flux-cored wire of T 19 12 3 L P / E316LT1 type designed for welding 1.4404, 1.4432 / 316L type stainless steels with good resistance to general, pitting and intergranular corrosion in chloride containing environments.
Intended for severe service conditions, e.g. in dilute hot acids. Also suitable for welding steels that are stabilised with titanium or niobium, such as 1.4571 / 316Ti for service temperatures not exceeding 400°C.
For higher temperatures a niobium-stabilised consumable such as FOXcore 318-T1 is required.
The scaling temperature is approximately 850°C in air. FOXcore 316L-T1 has a stronger arc and a faster freezing slag as compared to FOXcore 316L-T0 DG. It is designed for all-round welding and can be used in all positions without changing the parameter settings. Very good slag detachability and almost no spatter formation.
Due to the fast freezing rutile slag, the weldability is excellent also in the vertical-up and overhead positions.
The wide arc ensures even penetration and side-wall fusion to prevent lack of fusion. Suitable for service temperatures from –120°C to 400°C. For flat and horizontal welding positions, FOXcore 316L-T0 DG may be preferred.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - Foxcore 625-T1 FCAW 1.2mm 15Kg
Flux-cored wire electrode, high-alloyed, nickel-base
Classification: ENiCrMo3T1-4Nickel-base rutile flux-cored wire of Ni 6225 P / NiCrMo3-T1 type for welding of nickel-base alloys with high molybdenum content, e.g. Alloy 625 and Alloy 825, as well as super austenitic stainless steels such as 254 SMO® (1.4547 / UNS S31254).
With exceptional mechanical properties and low temperature ductility, this wire can be used for welding 9Ni-steels for cryogenic applications.
Suitable for pressure vessel fabrication in the service temperature range from –196°C to 550°C, otherwise resistant to scaling up to 1100°C (in S-free atmosphere). Can also be used for welding of dissimilar joints including low-alloyed “hard-to-weld” steels. Meets the corrosion test requirements per ASTM G48 Methods A, B and E (50°C).
The fast freezing slag offers excellent weldability and slag control.
The wire is optimised to minimise risk of forming porosity in all positions.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - Nibas 70/20-FD FCAW 1.2mm 15Kg
Flux-cored wire, high-alloyed, nickel-base Classification: ENiCr3T0-4
Suitable for high-quality weld joints of nickel-base alloys, joint welding of dissimilar steels and difficult-to-weld combinations including low-temperature steels up to 5% Ni, high-temperature and creep resistant materials, scaling resistant, unalloyed and high-alloyed Cr and CrNiMo stainless steels.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - BOHLER Q 71 RC FCAW 1.2mm 15Kg
Flux-cored wire, mild steel, rutile
Classification: E71T-9 C H4 / M H8All position rutile fl ux-cored wire with fast freezing slag system. Suitable for welding with shielding gas M21 and 100% CO 2 .
User friendly welding characteristics in all positions with one wire diameter 1.2 mm and same parameter setting.
Excellent mechanical properties, easy slag removal, low spatter loss, smooth, finely rippled bead surface, high X-ray safety.
For welding of unalloyed structural and fi ne-grained steels down to service temperatures of 40ºC with shielding gas M21.
The product performs to the highest productivity with significant savings in time and economical aspects when used for positional welding.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - BOHLER SAS 2 PW-FD FCAW 1.2mm 15Kg
Flux-cored wire, high-alloyed, austenitic stainless, stabilised
Classification: E347LT1/4Rutile flux-cored wire of T 19 9 Nb P / E347T1 type for welding of stainless steels such as 1.4546 / 347.
The corrosion resistance corresponds to that of the base material 308H, i.e. good resistance to general corrosion.
The fast freezing slag offers excellent weldability and slag control in all positions.
Easy handling and high deposition rate result in high productivity with excellent welding performance and very low spatter formation.
Increased travel speeds, as well as self-releasing slag with little demand for cleaning and pickling, provide considerable savings in time and money.
The wide arc ensures even penetration and side-wall fusion to prevent a lack of fusion. Stabilised with niobium and suitable for service temperatures from –120°C to 400°C.
The scaling temperature is approximately 850°C in air. For flat and horizontal welding positions, BÖHLER SAS 2-FD (FOXcore 347-T0) may be preferred.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - BOHLER Ti 52 T-FD FCAW 1.2mm 15Kg
Flux-cored wire, seamless, unalloyed, rutile type Classification: E71-T1C/T1M-H4
Seamless rutile flux cored wire for single- or multilayer welding of Carbon, Carbon-Manganese steels and similar types of steels including fine grain steels with Argon-CO2 shielding gas or pure CO2.
Main features: excellent weldability in all positions with high performance welding speed, very low spatter losses, good bead appearance, fast freezing and easy to remove slag.
This wire is especially suitable for ship building, structural steel work or wherever good bead appearance is required. D1.8 Seismic Supplement approved.
This product can be used in sour gas applications. (HIC tested acc. to NACE TM-0284).
Test values for SSC are available upon request. Typical hydrogen value 2.5 – 3.5ml/100g weld metal.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - BOHLER Ti 60 T-FD FCAW 1.2mm 15Kg
Flux-cored wire, seamless, high strength, rutile type Classification: E81T-Ni1 M-H4
Seamless rutile, Nickel alloyed, flux-cored wire for single- or multilayer welding of Carbon, CarbonManganese steels and high strength steels with Argon-CO2.
Main features: excellent weldability in all positions, excellent bead appearance, very low spatter losses, fast freezing and easy to remove slag.
The exceptional mechanical properties of this wire even at low temperatures (-60°C), also after post-weld heat treatment make it especially suitable for offshore applications.
The wire is CTOD tested at -10°C. (14°F) This product can be used in sour gas applications. (HIC tested acc. to NACE TM-0284).
Test values for SSC are available upon request.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - BOHLER Ti 71-TIC FCAW 1.2mm 15Kg
Flux-cored wire
Classification: E71-T1C -H8BOHLER Ti 71-T1C is a rutile flux cored wire with fast freezing slag.
Excellent welding characteristics in all positions, using 100% CO2 gas. Very good mechanical properties, easy slag removability, low spatter level, smooth and well-shaped beads with X-ray-quality.
Applicable in out of position welding, with higher productivity and less time for post weld cleaning.
Suitable for butt and fillet welding of hulls, storage tanks, mechanical and constructional steel structure and bridge.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Flux Cored Wire - BOHLER Ti 81 Ni-T1C FCAW 1.2mm 15Kg
Flux Cored Wire
Classification: E81T1-Ni1C-H8BOHLER Ti 81Ni-T1C is a rutile flux cored wire and designed for all-position welding with excellent CVN impact properties in as welded condition at - 40°C.
Excellent welding characteristics in all positions.
Very good mechanical properties, easy slag removability, low spatter level, smooth and good weld beads with X-ray-quality. Applicable in out-of-position welding, with higher productivity and less time for post weld cleaning.
Applicable for Single pass & multi passes weld.
Suitable for Butt, fillet welding of 490N/mm2 class high strength steel and low temperature steel of structure such as ships, bridges, buildings and storage tanks etc..
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler Solid Core Wire - BOHLER GMA 316LSi GMAW 0.9mm 15Kg
Stainless Steel MIG Wire
Classification: ER316LsiGMAW solid wire of type G 19 12 3 L Si / ER316LSi designed for high quality welding, good wetting and feeding characteristics as well as reliable corrosion resistance up to +400 °C.
Low temperature service down to -196°C
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler Solid Core Wire - BOHLER GMA 316LSi GMAW 1.0mm 15Kg
Stainless Steel MIG Wire
Classification: ER316LsiGMAW solid wire of type G 19 12 3 L Si / ER316LSi designed for high quality welding, good wetting and feeding characteristics as well as reliable corrosion resistance up to +400 °C.
Low temperature service down to -196°C
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler Solid Core Wire - 2507 P100 GTAW/GMAW 1.2mm 15Kg
Solid wire, high-alloyed, high corrosion resistant Classification: ER2594
Avesta 2507/P100 is intended for welding super duplex alloys such as SAF 2507, ASTM S32760, S32550 and S31260.
It can also be used for welding duplex type 2205 if extra high corrosion resistance is required, e.g. in root runs in tubes.
Avesta 2507/P100 provides a ferritic-austenitic weldment that combines many of the good properties of both ferritic and austenitic steel.
Welding without filler metal (i.e. TIG-dressing) is not allowed since the ferrite content will increase drastically and both mechanical and corrosion properties will be negatively affected.
Structure: Austenite with 45 – 55 % ferrite. Scaling temperature: Approx. 850 °C (air). Corrosion resistance: Excellent resistance to pitting and stress corrosion cracking in chloride-containing environments. Pitting resistance is in accordance with ASTM G48-A, better than 40 °C.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Solid Core Wire - BOHLER GMA 316L Si GMAW 1.2mm 15Kg
Stainless Steel MIG Wire
Classification: ER316LsiGMAW solid wire of type G 19 12 3 L Si / ER316LSi designed for high quality welding, good wetting and feeding characteristics as well as reliable corrosion resistance up to +400 °C.
Low temperature service down to -196°C
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler Solid Core Wire - 2507 P100 GTAW/GMAW 1.6mm 15Kg
Solid wire, high-alloyed, high corrosion resistant Classification: ER2594
Avesta 2507/P100 is intended for welding super duplex alloys such as SAF 2507, ASTM S32760, S32550 and S31260.
It can also be used for welding duplex type 2205 if extra high corrosion resistance is required, e.g. in root runs in tubes.
Avesta 2507/P100 provides a ferritic-austenitic weldment that combines many of the good properties of both ferritic and austenitic steel.
Welding without filler metal (i.e. TIG-dressing) is not allowed since the ferrite content will increase drastically and both mechanical and corrosion properties will be negatively affected.
Structure: Austenite with 45 – 55 % ferrite. Scaling temperature: Approx. 850 °C (air). Corrosion resistance: Excellent resistance to pitting and stress corrosion cracking in chloride-containing environments. Pitting resistance is in accordance with ASTM G48-A, better than 40 °C.
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler Metal Cored Wire Diamondspark 52 MC FCAW 1.2mm 15Kg
Seamless metal cored wire, unalloyed
Classification: E70-C6MH4Seamless all positional metal cored high efficiency wire especially designed for semi-automatic and fully automatic joint welding of unalloyed and fine-grained constructional steels.
Seamless technology guarantees a higher wire rigidity that give as benefits exact ignition and positioning accuracy.
Very high metal recovery between 95 and 97% are additional benefit of this wire.
Steady spray arc-like droplet transfer with minimal spatter formation, good penetration, high resistance to porosity, good behaviour as well as low hydrogen contents (~ 2ml/100g weld deposit) are further quality features of this metalcored wire.
Minimum oxide residues permit the welding of multi passes without the need for inter-run cleaning.
Ideal for horizontal and flat fillet welds.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Metal Cored Wire - BOHLER HL 51 L-MC FCAW 1.2mm 15Kg
Seamless metal cored wire, unalloyed
Classification: E70-C6MH4Seamless all positional metal-cored high-efficiency wire manufactured with seamless laser technology is especially designed for semi-automatic and fully automatic joint welding of unalloyed and fine-grained constructional steels.
The production technology by laser welding of the wire possesses higher rigidity- as a result it offers exact ignition and positioning accuracy.
Very high metal recovery between 95 and 97 % are additional benefits of this wire.
Steady spray arc-like droplet transfer with minimal spatter formation, good penetration, high resistance to porosity, good wetting behaviour as well as low hydrogen contents (< 2 ml/100 g weld deposit) are further quality features of this metal cored wire.
Minimum oxide residues permit the welding of multi passes without the need for inter-run cleaning. Ideal for horizontal and flat fillet welds.
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler Metal Cored Wire - BOHLER HL 51 L-MC FCAW 1.6mm 15Kg
Seamless metal cored wire, unalloyed
Classification: E70-C6MH4Seamless all positional metal-cored high-efficiency wire manufactured with seamless laser technology is especially designed for semi-automatic and fully automatic joint welding of unalloyed and fine-grained constructional steels.
The production technology by laser welding of the wire possesses higher rigidity- as a result it offers exact ignition and positioning accuracy.
Very high metal recovery between 95 and 97 % are additional benefits of this wire.
Steady spray arc-like droplet transfer with minimal spatter formation, good penetration, high resistance to porosity, good wetting behaviour as well as low hydrogen contents (< 2 ml/100 g weld deposit) are further quality features of this metal cored wire.
Minimum oxide residues permit the welding of multi passes without the need for inter-run cleaning. Ideal for horizontal and flat fillet welds.
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler SAW Wire/Flux Wire - Union S EM12K 2.0mm 15Kg
SAW wire/flux-combination, low alloyed
Classification: EM12KThis wire is for submerged arc welding applications. Excellent for a wide range of applications with single or multipass welding.
This wire contains low carbon, medium manganese, and low silicon. In combination with the below-listed Flux, it is recommended for joint welding of general and fine-grained structural steels, shipbuilding steels, bridge constructions, pressure vessels and pipe steels up to 420 Mpa. Min. Yield Strength.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler SAW Wire/Flux Wire - Union S EM12K 2.4mm 15Kg
SAW wire/flux-combination, low alloyed
Classification: EM12KThis wire is for submerged arc welding applications. Excellent for a wide range of applications with single or multipass welding.
This wire contains low carbon, medium manganese, and low silicon. In combination with the below-listed Flux, it is recommended for joint welding of general and fine-grained structural steels, shipbuilding steels, bridge constructions, pressure vessels and pipe steels up to 420 Mpa. Min. Yield Strength.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler SAW Wire/Flux Wire - Union S EM12K 3.2mm 15Kg
SAW wire/flux-combination, low alloyed
Classification: EM12KThis wire is for submerged arc welding applications. Excellent for a wide range of applications with single or multipass welding.
This wire contains low carbon, medium manganese, and low silicon. In combination with the below-listed Flux, it is recommended for joint welding of general and fine-grained structural steels, shipbuilding steels, bridge constructions, pressure vessels and pipe steels up to 420 Mpa. Min. Yield Strength.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler SAW Wire/Flux Wire - Union S EM12K 4.0mm 15Kg
SAW wire/flux-combination, low alloyed
Classification: EM12KThis wire is for submerged arc welding applications. Excellent for a wide range of applications with single or multipass welding.
This wire contains low carbon, medium manganese, and low silicon. In combination with the below-listed Flux, it is recommended for joint welding of general and fine-grained structural steels, shipbuilding steels, bridge constructions, pressure vessels and pipe steels up to 420 Mpa. Min. Yield Strength.
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta P5 E309MO MMAW 2.5mm 3.63kg
Stick electrode, high-alloyed, stainless, special applications
Classification: E309MO L-17Avesta P5 is a high-alloy low carbon electrode designed for welding dissimilar joints between stainless and mild or low-alloy steels. It can also be used for overlay welding on mild steel, providing an 18 Cr 8 Ni 2 Mo deposit from the very first layer.
Superior to 316L. When used for overlay welding on mild steel a corrosion resistance equivalent to that of 1.4401/ASTM 316 is obtained already in the first layer.
Base materials:
High-alloy low carbon electrode for surfacing unalloyed steel, joint welding molybdenum alloyed stainless steel to unalloyed steel and for welding clad material.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta 2205 3D MMAW 2.5mm 3.63kg
Covered Electrode, high-alloyed, duplex stainless
Classification: E2209-17Cr, Ni Mo alloyed duplex electrode for welding duplex steel such as 2205. For light to moderate thickness material, welding should be carried out as for ordinary austenitic stainless steel.
However the somewhat lower penetration and fluidity of the weld should be considered.
Very high quench rate and excessive time at red heat or above should be avoided to prevent excessive ferrite or formation of intermetallic phases.
Base materials:
Outokumpu 2205; EN 1.462; ASTM S32205; BS 318S13; NF Z3 CND 22-05 Az; SS 2377
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta 316/SKR MMAW 2.5mm 4.1kg
Stick electrode, high-alloyed
Classification: E316L-17Cr-Ni-Mo electrode for all position welding to ASTM 316 and 316L stainless steel.
Weld metal features a good resistance against intergranular corrosion ( IGC ASTM A262 Practice E )
Base materials:
Outokumpu 4436, 4432, 4429, 4571; EN 1.4436, 1.4432, 1.4429, 1.4571; ASTM 316, 316L, S31653, 316Ti; BS 316S33, 316S3, 316S63, 320S31; NF Z7 CND 18-12-03, Z3 CND 17-12-03, Z3 CND 17-12-Az, Z6 CND 17-12; SS 2343, 2353, 2375, 2350.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta 309L MMAW 2.5mm 3.63kg
Stick electrode, Rutile, High-alloyed, Chemical resistant
Classification: E309L-17Avesta 309L is a high-alloy low carbon electrode designed for welding dissimilar joints between stainless and mild or low-alloy steels. The electrode is well suited as a buffer layer when overlay welding on mild steels, providing an 18 Cr 8 Ni deposit from the first layer.
Avesta 309L can also be used for welding some high-temperature steels, such as 1.4833/ASTM 309S. Corrosion resistance: Superior to 308L. When used for overlay welding on mild steel a corrosion resistance equivalent to that of 1.4301/ASTM 304 is obtained already in the first layer.
Base materials:
High-alloy low carbon electrode for surfacing unalloyed steel, joint welding molybdenum-alloyed stainless steel to unalloyed steel and for welding clad material.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta 308L/MVR MMAW 2.5mm 3.63kg
Stick Electrode, high-alloyed
Classification: E308L-17Is a Cr-Ni electrode for all position of ASTM 304 and 304L stainless steels.
Weld metal features a good resistance against intergranular corrosion (IGC ASTM A262 Practice E)
Base materials:
Outokumpu 4301, 4307, 4311, 4541; EN 1.4301, 1.4307, 1.4311, 1.4541; ASTM 304, 304L, 304LN, 321; BS 304S31, 304S11, 304S61, 321S31; NF Z7 CN 18-09, Z3 CN 18-10, Z3 CN 18-10 Az, Z6 CNT 18-10; SS 2333, 2352, 2371, 2337.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta 253MA MMAW 2.5mm 4.0kg
Stick electrode, high-alloyed, austenitic stainless, creep resistant
Classification: E 21 10 N RRutile coated electrode, designed for welding the high-temperature stainless steel 253 MA®, used for furnaces, combustion chambers, and burners.
Both the steel and filler metal offers excellent resistance to oxidation to 1100 give °C. The chemical composition of Avesta 253 MA has a balanced ferrite content of max. 6 FN to give a crack-resistant weld metal.
Excellent resistance to high-temperature corrosion. Not intended for applications exposed to wet corrosion.
Base materials:
1.4835 X9CrN.iSiNCe21-11-2, 1.4818 X6CrNiSiNCe19-10, S30815, S30415, 253 MA®, 153 MA™
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX CM 2 Kb MMAW 2.5mm 3.0kg
Stick electrode, low-alloyed, creep resistant
Classification: E9018-B3 H4 RBasic coated, core wire alloyed stick electrode for welding 2.25% Cr 1% Mo alloyed steels. Approved in long-term condition up to +600ºC service temperature. Applicable for welds in refineries, boiler construction, and thermal power plants.
Core wire alloyed electrode which will provide reliable creep rupture properties. Crack resistant and ductile deposit, high creep rupture strength, low hydrogen content (acc. AWS condition HD < 4 ml/100 g).
Good weldability in all positions except vertical down. Deposit is nitride able and heat treatable. Metal recovery approximately 110%. Suitable for Step Cooling.
Base materials:
High temperature steels and similar alloyed cast steels, QT-steels similar alloyed up to 980 MPa tensile strength, similar alloyed case hardening steels, nitriding steels
1.7380 10CrMo9-10, 1.7276 10CrMo11, 1.7281 16CrMo9-3, 1.7383 11CrMo9-10, 1.7379 G17CrMo9-10, 1.7382 G19CrMo9-10 ASTM A 182 Gr. F22; A 213 Gr. T22; A 234 Gr. WP22; 335 Gr. P22; A 336 Gr. F22; A 426 Gr. CP22
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX CM 5 Kb MMAW E8018 2.5mm 3.0kg
Basic stick electrode, high-alloyed, creep resistant
Classification: E8018-B6H4RBasic coated, core wire alloyed electrode for creep resistant steels suited in pressure vessels and in the crude oil industry.
Preferably suited for X12CrMo5 (5 Cr 0.5 Mo) steels. Approved in long-term condition up to +650°C service temperature. High crack resistance, very low hydrogen content (acc. AWS condition HD < 4 ml/100g).
Good weldability in all positions except vertical down. The weld deposit is heat treatable. Metal recovery approx. 115%.
Base materials:
Creep resistant steels and similar alloyed cast steels, QT-steels similar alloyed up to 1180 MPa tensile strength
1.7362 X12CrMo5, ASTM A 182 Gr. F5; A 193 Gr. B5; A 213 Gr. T5; A217 Gr. C5; A 234 Gr. WP5; A 314 Gr. 501; A335 Gr. P5 u. P5c; A 369 Gr. FB 5; A 387 Gr. 5; A 426 Gr. CP5
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S EV Pipe-1 E7016-1H4R 2.5mm 5.0kg
Basic stick electrode for vertical-up welding, pipe welding
Classification: E7016-1H4R
Bohler FOX EV PIPE is a basic coated electrode, suited for positional welding of root passes using DC ( – ) as well as for filler and cover passes of pipes, tubes, and plates on DC ( + ), or even AC. Good gap bridging ability together with easy slag removal ensures minimum grinding.
Weld- metal toughness is available down to -45°C. BÖHLER FOX EV PIPE offers considerable time savings against AWS E7018 type electrodes when welding root passes due to increased travel speeds.
Also the use of dia. 3.2 mm is possible for root passes in case of wall thicknesses of 8 mm and more.
Bohler FOX EV PIPE can be used in sour gas applications (HIC-Test acc. to NACE TM-02-84). Test values for SSC-test are available too.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S EV 47 E7016-1H4R 2.5mm 5.0kg
Stick Electrode, Unalloyed
Classification: E7016-1H4RBasic electrode for high-quality welds. Good weld ability in all positions except vertical-down. Metal recovery about 110 %. Very low hydrogen content (according AWS condition HD < 4 ml/100g weld metal).
Weld metal extremely ductile, crack resistant and ageing resistant thus especially suited for rigid welds with heavy seam cross sections.
Base materials: Steels up to a yield strength of 380 MPa (52 ksi)
S235JR-S355JR, S235JO-S355JO, S235J2-S355J2, S275N-S355N, S275M-S355M, P235GH-P355GH, P355N, P275NL1-P355NL1, P215NL, P265NL, P285NH-P355NH, P195TR1-P265TR1, P195TR2-P265TR2, P195GH-P265GH, L245NB-L360NB, L245MB-L360MB, GE200-GE240
Ship-building steels: A, B, D, E, A 32-E 36
ASTM A 106 Gr. A, B, C; A 181 Gr. 60, 70; A 283 Gr. A, C; A 285 Gr. A, B, C; A 350 Gr. LF1, LF2; A 414 Gr. A, B, C, D, E, F, G; A 501 Gr. B; A 513 Gr. 1018; A 516 Gr. 55, 60, 65, 70; A 573 Gr. 58, 65, 70; A 588 Gr. A, B; A 633 Gr. A, C, D; A 662 Gr. A, B, C; A 678 Gr. A, B; A 711 Gr. 1013; API 5 L Gr. B, X42, X52, X56
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX EV 50 E7018 H4R 2.5mm 5.0kg
Stick Electrode, Unalloyed basic
Classification: E7018 H4RBasic covered electrode with very good welding characteristics including out of position work.
Weld metal recovery about 115%*.
Crack-free weld metal when welding high-carbon steels.
Suitable for use in tank construction, boiler and pressure vessel manufacturer, apparatus engineering, vehicle manufacture, offshore applications and ship building.
Base materials:
S235JRG2 – S355J2, E295, E335, C35; boiler steels P235GH, P265 GH, P295GH, P355GH; fine grained structural steels up to S420N; shipbuilding steels A, B, D, E; offshore steels; pipe steels P265, P295, L290NB – L415NB, L290MB – L415MB, X42 – X56; cast steels GS-38, GS-45, GS-52; ageing resistant steels Ast35 – Ast52; SA 516 Gr 60, 65, 70; SA333 Gr 6.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S 2.5 Ni E8018-C1H4R 2.5mm 5.0kg
Stick electrode, low-alloy cryogenic
Classification: E8018-C1H4RNi-alloy, basic coated stick electrode for unalloyed and Ni-alloy fine-grained structural steels. Tough, crack resistant weld metal. The weld metal is cryogenic down to -80oC.
Ideal weldability in all positions except for vertical down. Very low hydrogen content (under AWS condition HD < 4mL/100g).
Base materials:
Cryogenic structural and Ni-alloy steels, special cryogenic shipbuilding steels. 10Ni14, 12Ni14, 13MnNi6-3, 15NiMn6, S275N-S460N, S275NL-S460NL, S275M-S460M, S275ML-S460ML, P275NL1-P460NL1, P275NL2-P460NL2 ASTM A 203 Gr.D, E;A 333 Gr. 3; A 350 Gr. LF1, LF2, LF3; A 420 Gr. WPL3, WPL6; A516 Gr.60, 65: AA 529 Gr. 50; A 572 Gr. 42, 65; A 633 Gr. A, D, E; A 622 Gr. A, B, C; A 707 Gr. L1, L2, L3; A 738 Gr. A; A 841 A, B, C.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S 308L-16 MMAW 2.5mm 3.63kg
Stick electrode, low-alloyed
Classification: E308L-16Bohler Fox S 308L-16 is a Cr-Ni electrode for all position welding of 1.4301/ASTM 304 types stainless steel. corrosion resistance: very good under fairly severe conditions, e.g. in oxidation acids and cold or dilute reducing acids.
Base materials:
ASTM 304, 304L; BS304S31, 304S11, 304S61; SS2333, 2352
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S 309L-16 MMAW 2.5mm 3.63kg
Stick electrode, low-alloyed, basic
Avesta 309L-Si is a high-alloy 23 Cr 13 Ni wire primarily intended for surfacing of low-alloy steels and dissimilar welding between mild steel and stainless steels, offering a ductile and crack resistant weldment. The chemical composition, when surfacing, is equivalent to that of ASTM 304 from the first run.
One or two layers of 309L are usually combined with a final layer of 308L, 316L or 347. Structure: Austenite with 5 – 10 % ferrite. Scaling temperature: Approx. 1000 °C (air).
Corrosion resistance: Superior to type 308L. When fur facing on mild steel a corrosion resistance equivalent to ASTM 304 is obtained at the first bead.
Base materials:
Avesta 309L-Si is primarily used when surfacing unalloyed or low-alloy steels and when joining non-molybdenum-alloyed stainless and carbon steels.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S 316L-16 MMAW 2.5mm 3.63kg
Stick electrode, high-alloyed
Classification: E316L-16Low carbon, core wire alloyed, austenitic stick electrode with rutile coating. For application in all branches of industry where same-type steels, including higher carbon-seels and feritic 13% chrome steels are welded. Special fine welding properties, excellent welding with AC power and high resistance to hot cracking in the weld metal are features of this product.
Resists intergranular corrosion up to +400°C.
Base materials:
ASTM 316 - 316L-S31653; SS 2343-2353-2375; BS316S33,316S13
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S OHV E6013 MMAW 2.5mm 5.0kg
Stick electrode, Rutile - cellulosic, unalloyed
Classification: E6013Rutile-cellulosic electrode with good weldability in all positions including vertical down. Most popular E6013 type, suitable for small transformers with low OCV. Very good operating characteristics. The Slag Covering and its removability are good. Flexible coating, good for tack welding.
Versatile applications in structural welding, automotive fabrication, boiler and tank welding, and in shipbuilding. Also suitable for galvanized components.
Base materials:
Steels up to a yield strength of 380 N/mm2 (52 ksi)
S275JR, S235J0G3 - S355J0G3, P235GH, P265GH, P255NH, P235T1, P355T1, P235T2-P355T2, P235G1TH, P255G1TH, L210 - L360NB, L290MB, S235JRS1 - S235J0S1, S235JRS2 - S235J0S2
ASTM A36 a. A53 Gr. all; A106 Gr. A, B, C A 135 Gr. A, B; A283 Gr. A, B, C, D; A366; A285
Gr. A, B, C; A500 Gr. A, B, C; A570 Gr. 30, 33, 36, 40, 45; A607 Gr. 45; A668 Gr. A, B; A907
Gr. 30, 33, 36, 40; A935 Gr.45; A936 Gr. 50; API 5 L Gr. B, X42 - X52
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX SAS 2-A FCAW E347 2.5mm 4.1kg
Flux-cored wire, high-alloyed, stainless
Classification: E347-17Rutile coated core wire alloyed, stabilised austenitic electrode, mainly for Ti or Nb stabilised 1.4541 / 321 / 347 CrNi-steel grades.
Designed for first class weld seems and easy handling on AC or DC. High current carrying capacity, minimum spatter formation, self-releasing slag, smooth and clean weld profile, safety against formation of porosity due to moisture resistant coating.
The fully alloyed core wire ensures the most reliable corrosion resistance. Resistant to intergranular corrosion up to +400 °C.
Base materials:
1 1.4550 X6CrNiNb18-10, 1.4541 X6CrNiTi18-10, 1.4552 GX5CrNiNb19-11, 1.4301 X5CrNi18-10, 1.4312 GX10CrNi18-8, 1.4546 X5CrNiNb18-10, 1.4311 X2CrNiN18-10, 1.4306 X2CrNi19-11
AISI 347, 321,302, 304, 304L, 304LN, ASTM A296 Gr. CF 8 C, A157 Gr. C9, A320 Gr. B8C or D
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Phoenix Spezial D MMAW 2.5mm 4.1kg
Stick electrode, Unalloyed basic
Basic double-coated electrode with excellent weldability in all position except vertical down. Especially suited for out-of-position welding thanks to the weld controlled arc.
Excellent root penetration. Good suitability for welding in AC.
Minimum spatter loss, very easy slag removal with uniform beads. Well suited for lower OCV power sources. Low hydrogen content in the weld deposit (HD < 10 ml/100 g deposit)
Base materials:
Steels up to a yield strength of 420 MPa (60 ksi)
S235JR-S355JR, S235JO-S355JO, S235J2-S355J2, S275N-S420N, S275M-S420M, P235GHP355GH, P355N, P285NH-P420NH, P195TR1-P265TR1, P195TR2-P265TR2, P195GH-P265GH, L245NB-L415NB, L245MB-L415MB, GE200-GE240
ASTM A 106 Gr. A, B, C; A 181 Gr. 60, 70; A 283 Gr. A, C; A 285 Gr. A, B, C; A 414 Gr. A, B, C, D, E, F, G; A 501 Gr. B; A 516 Gr. 55, 60, 65, 70; A 573 Gr. 58, 65, 70; A 588 Gr. A, B; A 633 Gr. A, C, D; A 662 Gr. A, B, C; A 678 Gr. A, B; A 711 Gr. 1013; API 5 L Gr. B, X42, X52, X56, X60
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - T Phoenix Cr1Mo SC E8018 2.5mm 5.0kg
Low Alloy Steel Covered Electrode
Classification: E8018 B2H4RBasic covered Cr-Mo alloyed electrode, Very good weld ability in out of position work.
Creep resistant in short time rang up to 500°(932°F) and in long time rang up to 570°(1058°F) Low content trace elements.
Largely insensitive to long-term embrittlement.
Suitable for chemical apparatus engineering for the welding of gasification, heavy-duty boile and super-heater fabrication and hot steam pipes.
Base materials:
13CrMo 4-5 (AISI/AWS A182-F 11&12), GS-22 CrMo 5-4.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - T Phoenix Cr2Mo SC E9018 2.5mm 4.5kg
Low Alloy Steel Covered Electrode Classification: E9018-B3H4R
Suited for the welding of 2.25Cr-1Mo low alloyed and creep resistant steels in boiler, tank, and pipeline etc.
Base materials:
10 CrMo 9-10. 12 CrMo 9-10, 10 CrSiMoV 7, 15CrMoV 5-10, SA335Gr.P22, SA217Gr. Wc9
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - T Phoenix CrMo 9 V Ni E9015 2.5mm 5.0kg
Steel Covered Electrode, Low alloyed
Classification: E9015-B91Basic-covered Cr Mo Ni V Nb alloyed electrode
Good welding characteristics in all position work, high-temperature weld metal of identical composition
For quenched and tempered 9% chromium steel, in particular P91/T91 according to AWS.
Preheating and interpass temperature shall be 200° and under 280° Cool till to room temperature before PWHT, for which the heating and cooling rate shall be 100°/hr.
Base materials:
X10CrMoVNb9 - 1 (1.4903), A213 - T91, A335 - P91
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - T Phoenix Ni E8018 -C3H4R 2.5mm 5.0kg
Steel Covered Electrode, Low Alloyed
Classification: E8018-C3H4RVery good weldability in out of position work; excellent cold toughness at -60°C.
Low content trace elements.
Suited for welding 16MnDR steel and other low temperature for low temperature pressure vessel, tank and pipe.
Base materials:
16MnDR,15MnNi63(TSB370),C22.8S1.GS-C 25,S275N-S4420N
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode -Thermanit NiMo 100 E10018 2.5mm 4.2kg
Stick electrode, low-alloyed, basic
Classification: E10018-D2 H4Basic covered MnNiMo alloyed electrode. Very low H2-content ≤4 mI/11g; extremely high resistance to cracking and high toughness at temperatures as Iow as -40 °c (-40 °F).
For creep resistant steels and cast steel grades, valves, and oil tools according to sour gas specification; post-weld stress-relieving according to the parent metal.
Base materials:
GS-30 CrMo V64,
Steels acc. ASTM A 487-4Q; AISI 4130
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode -Thermanit Chromo 9V Mod MMAW 2.5mm 3.0kg
Stick electrode, basic coated, creep resistant
Classification: E9015-B9H4RThe basic coated CrMoVNB alloyed electrode is specially designed for welding of creep resistant tempered martensitic 9% Cr steels used for turbine and boiler fabrication in thermal power plants as well as in the chemical industry.
Thermanit Chromo 9 V Mod provides good welding characteristics in all positions except vertical down, a stable arc, low spattering, good slag detachability and excellent striking and re-striking properties.
The chemical composition is optimised in order to provide a high creep resistant and ductile weld metal and meets the requirement for restricted Mn + Ni content (≤ 1 wt. %). It is characterised by low hydrogen content and low level of trace elements.
This electrode has a half-synthetic cover concept.
Base materials:
Modified 9Cr-1Mo steels like 1.4903, X10CrMoVNb9-1, GX12CrMoVNbN9-1, ASTM Grade 91
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler Stick Electrode - FOX CM 2 Kb MMAW 3.2mm 4.4kg
Stick electrode, low-alloyed, creep resistant
Classification: E9018-B3 H4 RBasic coated, core wire alloyed stick electrode for welding 2.25% Cr 1% Mo alloyed steels. Approved in long-term condition up to +600ºC service temperature. Applicable for welds in refineries, boiler construction, and thermal power plants.
Core wire alloyed electrode which will provide reliable creep rupture properties. Crack resistant and ductile deposit, high creep rupture strength, low hydrogen content (acc. AWS condition HD < 4 ml/100 g).
Good weldability in all positions except vertical down. Deposit is nitride able and heat treatable. Metal recovery approximately 110%. Suitable for Step Cooling.
Base materials:
High temperature steels and similar alloyed cast steels, QT-steels similar alloyed up to 980 MPa tensile strength, similar alloyed case hardening steels, nitriding steels
1.7380 10CrMo9-10, 1.7276 10CrMo11, 1.7281 16CrMo9-3, 1.7383 11CrMo9-10, 1.7379 G17CrMo9-10, 1.7382 G19CrMo9-10 ASTM A 182 Gr. F22; A 213 Gr. T22; A 234 Gr. WP22; 335 Gr. P22; A 336 Gr. F22; A 426 Gr. CP22
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX CM 5 Kb MMAW E8018 3.2mm 4.0kg
Basic stick electrode, high-alloyed, creep resistant
Classification: E8018-B6H4RBasic coated, core wire alloyed electrode for creep resistant steels suited in pressure vessels and in the crude oil industry.
Preferably suited for X12CrMo5 (5 Cr 0.5 Mo) steels. Approved in long-term condition up to +650°C service temperature. High crack resistance, very low hydrogen content (acc. AWS condition HD < 4 ml/100g).
Good weldability in all positions except vertical down. The weld deposit is heat treatable. Metal recovery approx. 115%.
Base materials:
Creep resistant steels and similar alloyed cast steels, QT-steels similar alloyed up to 1180 MPa tensile strength
1.7362 X12CrMo5, ASTM A 182 Gr. F5; A 193 Gr. B5; A 213 Gr. T5; A217 Gr. C5; A 234 Gr. WP5; A 314 Gr. 501; A335 Gr. P5 u. P5c; A 369 Gr. FB 5; A 387 Gr. 5; A 426 Gr. CP5
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta P5 E309MO MMAW 3.2mm 4.1kg
Stick electrode, high-alloyed, stainless, special applications
Classification: E309MO L-17Avesta P5 is a high-alloy low carbon electrode designed for welding dissimilar joints between stainless and mild or low-alloy steels. It can also be used for overlay welding on mild steel, providing an 18 Cr 8 Ni 2 Mo deposit from the very first layer.
Superior to 316L. When used for overlay welding on mild steel a corrosion resistance equivalent to that of 1.4401/ASTM 316 is obtained already in the first layer.
Base materials:
High-alloy low carbon electrode for surfacing unalloyed steel, joint welding molybdenum alloyed stainless steel to unalloyed steel and for welding clad material.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta 2205 3D MMAW 3.2mm 4.1kg
Covered Electrode, high-alloyed, duplex stainless
Classification: E2209-17Cr, Ni Mo alloyed duplex electrode for welding duplex steel such as 2205. For light to moderate thickness material, welding should be carried out as for ordinary austenitic stainless steel.
However the somewhat lower penetration and fluidity of the weld should be considered.
Very high quench rate and excessive time at red heat or above should be avoided to prevent excessive ferrite or formation of intermetallic phases.
Base materials:
Outokumpu 2205; EN 1.462; ASTM S32205; BS 318S13; NF Z3 CND 22-05 Az; SS 2377
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta 316/SKR MMAW 3.2 4.1kg
Stick electrode, high-alloyed
Classification: E316L-17Cr-Ni-Mo electrode for all position welding to ASTM 316 and 316L stainless steel.
Weld metal features a good resistance against intergranular corrosion ( IGC ASTM A262 Practice E )
Base materials:
Outokumpu 4436, 4432, 4429, 4571; EN 1.4436, 1.4432, 1.4429, 1.4571; ASTM 316, 316L, S31653, 316Ti; BS 316S33, 316S3, 316S63, 320S31; NF Z7 CND 18-12-03, Z3 CND 17-12-03, Z3 CND 17-12-Az, Z6 CND 17-12; SS 2343, 2353, 2375, 2350.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta 309L MMAW 3.2mm 4.1kg
Stick electrode, Rutile, High-alloyed, Chemical resistant
Classification: E309L-17Avesta 309L is a high-alloy low carbon electrode designed for welding dissimilar joints between stainless and mild or low-alloy steels. The electrode is well suited as a buffer layer when overlay welding on mild steels, providing an 18 Cr 8 Ni deposit from the first layer.
Avesta 309L can also be used for welding some high-temperature steels, such as 1.4833/ASTM 309S. Corrosion resistance: Superior to 308L. When used for overlay welding on mild steel a corrosion resistance equivalent to that of 1.4301/ASTM 304 is obtained already in the first layer.
Base materials:
High-alloy low carbon electrode for surfacing unalloyed steel, joint welding molybdenum-alloyed stainless steel to unalloyed steel and for welding clad material.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta 308L/MVR MMAW 3.2mm 4.1kg
Stick Electrode, high-alloyed
Classification: E308L-17Is a Cr-Ni electrode for all position of ASTM 304 and 304L stainless steels.
Weld metal features a good resistance against intergranular corrosion (IGC ASTM A262 Practice E)
Base materials:
Outokumpu 4301, 4307, 4311, 4541; EN 1.4301, 1.4307, 1.4311, 1.4541; ASTM 304, 304L, 304LN, 321; BS 304S31, 304S11, 304S61, 321S31; NF Z7 CN 18-09, Z3 CN 18-10, Z3 CN 18-10 Az, Z6 CNT 18-10; SS 2333, 2352, 2371, 2337.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta 253MA MMAW 3.2mm 4.1kg
Stick electrode, high-alloyed, austenitic stainless, creep resistant
Classification: E 21 10 N RRutile coated electrode, designed for welding the high-temperature stainless steel 253 MA®, used for furnaces, combustion chambers, and burners.
Both the steel and filler metal offers excellent resistance to oxidation to 1100 give °C. The chemical composition of Avesta 253 MA has a balanced ferrite content of max. 6 FN to give a crack-resistant weld metal.
Excellent resistance to high-temperature corrosion. Not intended for applications exposed to wet corrosion.
Base materials:
1.4835 X9CrN.iSiNCe21-11-2, 1.4818 X6CrNiSiNCe19-10, S30815, S30415, 253 MA®, 153 MA™
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S EV Pipe-1 E7016 3.2mm 5.0kg
Basic stick electrode for vertical-up welding, pipe welding
Classification: E7016-1H4RBohler FOX EV PIPE is a basic coated electrode, suited for positional welding of root passes using DC ( – ) as well as for filler and cover passes of pipes, tubes, and plates on DC ( + ), or even AC. Good gap bridging ability together with easy slag removal ensures minimum grinding.
Weld- metal toughness is available down to -45°C. BÖHLER FOX EV PIPE offers considerable time savings against AWS E7018 type electrodes when welding root passes due to increased travel speeds.
Also the use of dia. 3.2 mm is possible for root passes in case of wall thicknesses of 8 mm and more.
Bohler FOX EV PIPE can be used in sour gas applications (HIC-Test acc. to NACE TM-02-84). Test values for SSC-test are available too.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S EV 47 E7016-1H4R 3.2mm 5.0kg
Stick Electrode, Unalloyed
Classification: E7016-1H4RBasic electrode for high-quality welds. Good weld ability in all positions except vertical-down. Metal recovery about 110 %. Very low hydrogen content (according AWS condition HD < 4 ml/100g weld metal).
Weld metal extremely ductile, crack resistant and ageing resistant thus especially suited for rigid welds with heavy seam cross sections.
Base materials: Steels up to a yield strength of 380 MPa (52 ksi)
S235JR-S355JR, S235JO-S355JO, S235J2-S355J2, S275N-S355N, S275M-S355M, P235GH-P355GH, P355N, P275NL1-P355NL1, P215NL, P265NL, P285NH-P355NH, P195TR1-P265TR1, P195TR2-P265TR2, P195GH-P265GH, L245NB-L360NB, L245MB-L360MB, GE200-GE240
Ship-building steels: A, B, D, E, A 32-E 36
ASTM A 106 Gr. A, B, C; A 181 Gr. 60, 70; A 283 Gr. A, C; A 285 Gr. A, B, C; A 350 Gr. LF1, LF2; A 414 Gr. A, B, C, D, E, F, G; A 501 Gr. B; A 513 Gr. 1018; A 516 Gr. 55, 60, 65, 70; A 573 Gr. 58, 65, 70; A 588 Gr. A, B; A 633 Gr. A, C, D; A 662 Gr. A, B, C; A 678 Gr. A, B; A 711 Gr. 1013; API 5 L Gr. B, X42, X52, X56
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX EV 50 E7018 H4R 3.2mm 5.0kg
Stick Electrode, Unalloyed basic
Classification: E7018 H4RBasic covered electrode with very good welding characteristics including out of position work.
Weld metal recovery about 115%*.
Crack-free weld metal when welding high-carbon steels.
Suitable for use in tank construction, boiler and pressure vessel manufacturer, apparatus engineering, vehicle manufacture, offshore applications and ship building.
Base materials:
S235JRG2 – S355J2, E295, E335, C35; boiler steels P235GH, P265 GH, P295GH, P355GH; fine grained structural steels up to S420N; shipbuilding steels A, B, D, E; offshore steels; pipe steels P265, P295, L290NB – L415NB, L290MB – L415MB, X42 – X56; cast steels GS-38, GS-45, GS-52; ageing resistant steels Ast35 – Ast52; SA 516 Gr 60, 65, 70; SA333 Gr 6.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S 2.5 Ni E8018-C1H4R 3.2mm 5.0kg
Stick electrode, low-alloy cryogenic
Classification: E8018-C1H4RNi-alloy, basic coated stick electrode for unalloyed and Ni-alloy fine-grained structural steels. Tough, crack resistant weld metal. The weld metal is cryogenic down to -80oC.
Ideal weldability in all positions except for vertical down. Very low hydrogen content (under AWS condition HD < 4mL/100g).
Base materials:
Cryogenic structural and Ni-alloy steels, special cryogenic shipbuilding steels. 10Ni14, 12Ni14, 13MnNi6-3, 15NiMn6, S275N-S460N, S275NL-S460NL, S275M-S460M, S275ML-S460ML, P275NL1-P460NL1, P275NL2-P460NL2 ASTM A 203 Gr.D, E;A 333 Gr. 3; A 350 Gr. LF1, LF2, LF3; A 420 Gr. WPL3, WPL6; A516 Gr.60, 65: AA 529 Gr. 50; A 572 Gr. 42, 65; A 633 Gr. A, D, E; A 622 Gr. A, B, C; A 707 Gr. L1, L2, L3; A 738 Gr. A; A 841 A, B, C.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S 308L-16 MMAW 3.2mm 4.1kg
Stick electrode, low-alloyed
Classification: E308L-16Bohler Fox S 308L-16 is a Cr-Ni electrode for all position welding of 1.4301/ASTM 304 types stainless steel. corrosion resistance: very good under fairly severe conditions, e.g. in oxidation acids and cold or dilute reducing acids.
Base materials:
ASTM 304, 304L; BS304S31, 304S11, 304S61; SS2333, 2352
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S 309L-16 MMAW 3.2mm 4.1kg
Stick electrode, low-alloyed, basic
Avesta 309L-Si is a high-alloy 23 Cr 13 Ni wire primarily intended for surfacing of low-alloy steels and dissimilar welding between mild steel and stainless steels, offering a ductile and crack resistant weldment. The chemical composition, when surfacing, is equivalent to that of ASTM 304 from the first run.
One or two layers of 309L are usually combined with a final layer of 308L, 316L or 347. Structure: Austenite with 5 – 10 % ferrite. Scaling temperature: Approx. 1000 °C (air).
Corrosion resistance: Superior to type 308L. When fur facing on mild steel a corrosion resistance equivalent to ASTM 304 is obtained at the first bead.
Base materials:
Avesta 309L-Si is primarily used when surfacing unalloyed or low-alloy steels and when joining non-molybdenum-alloyed stainless and carbon steels.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S 316L-16 MMAW 3.2mm 4.1kg
Stick electrode, high-alloyed
Classification: E316L-16Low carbon, core wire alloyed, austenitic stick electrode with rutile coating. For application in all branches of industry where same-type steels, including higher carbon-seels and feritic 13% chrome steels are welded. Special fine welding properties, excellent welding with AC power and high resistance to hot cracking in the weld metal are features of this product.
Resists intergranular corrosion up to +400°C.
Base materials:
ASTM 316 - 316L-S31653; SS 2343-2353-2375; BS316S33,316S13
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S OHV E6013 MMAW 3.2mm 5.0kg
Stick electrode, Rutile - cellulosic, unalloyed
Classification: E6013Rutile-cellulosic electrode with good weldability in all positions including vertical down. Most popular E6013 type, suitable for small transformers with low OCV. Very good operating characteristics. The Slag Covering and its removability are good. Flexible coating, good for tack welding.
Versatile applications in structural welding, automotive fabrication, boiler and tank welding, and in shipbuilding. Also suitable for galvanized components.
Base materials:
Steels up to a yield strength of 380 N/mm2 (52 ksi)
S275JR, S235J0G3 - S355J0G3, P235GH, P265GH, P255NH, P235T1, P355T1, P235T2-P355T2, P235G1TH, P255G1TH, L210 - L360NB, L290MB, S235JRS1 - S235J0S1, S235JRS2 - S235J0S2
ASTM A36 a. A53 Gr. all; A106 Gr. A, B, C A 135 Gr. A, B; A283 Gr. A, B, C, D; A366; A285
Gr. A, B, C; A500 Gr. A, B, C; A570 Gr. 30, 33, 36, 40, 45; A607 Gr. 45; A668 Gr. A, B; A907
Gr. 30, 33, 36, 40; A935 Gr.45; A936 Gr. 50; API 5 L Gr. B, X42 - X52
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX SAS 2-A FCAW E347 3.2mm 4.1kg
Flux-cored wire, high-alloyed, stainless
Classification: E347-17Rutile coated core wire alloyed, stabilised austenitic electrode, mainly for Ti or Nb stabilised 1.4541 / 321 / 347 CrNi-steel grades.
Designed for first class weld seems and easy handling on AC or DC. High current carrying capacity, minimum spatter formation, self-releasing slag, smooth and clean weld profile, safety against formation of porosity due to moisture resistant coating.
The fully alloyed core wire ensures the most reliable corrosion resistance. Resistant to intergranular corrosion up to +400 °C.
Base materials:
1 1.4550 X6CrNiNb18-10, 1.4541 X6CrNiTi18-10, 1.4552 GX5CrNiNb19-11, 1.4301 X5CrNi18-10, 1.4312 GX10CrNi18-8, 1.4546 X5CrNiNb18-10, 1.4311 X2CrNiN18-10, 1.4306 X2CrNi19-11
AISI 347, 321,302, 304, 304L, 304LN, ASTM A296 Gr. CF 8 C, A157 Gr. C9, A320 Gr. B8C or D
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Phoenix Spezial D MMAW 3.2mm 4.1kg
Stick electrode, Unalloyed basic
Basic double-coated electrode with excellent weldability in all position except vertical down. Especially suited for out-of-position welding thanks to the weld controlled arc.
Excellent root penetration. Good suitability for welding in AC.
Minimum spatter loss, very easy slag removal with uniform beads. Well suited for lower OCV power sources. Low hydrogen content in the weld deposit (HD < 10 ml/100 g deposit)
Base materials:
Steels up to a yield strength of 420 MPa (60 ksi)
S235JR-S355JR, S235JO-S355JO, S235J2-S355J2, S275N-S420N, S275M-S420M, P235GHP355GH, P355N, P285NH-P420NH, P195TR1-P265TR1, P195TR2-P265TR2, P195GH-P265GH, L245NB-L415NB, L245MB-L415MB, GE200-GE240
ASTM A 106 Gr. A, B, C; A 181 Gr. 60, 70; A 283 Gr. A, C; A 285 Gr. A, B, C; A 414 Gr. A, B, C, D, E, F, G; A 501 Gr. B; A 516 Gr. 55, 60, 65, 70; A 573 Gr. 58, 65, 70; A 588 Gr. A, B; A 633 Gr. A, C, D; A 662 Gr. A, B, C; A 678 Gr. A, B; A 711 Gr. 1013; API 5 L Gr. B, X42, X52, X56, X60
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - T Phoenix Cr1Mo SC E8018 3.2mm 5.0kg
Low Alloy Steel Covered Electrode
Classification: E8018 B2H4RBasic covered Cr-Mo alloyed electrode, Very good weld ability in out of position work.
Creep resistant in short time rang up to 500°(932°F) and in long time rang up to 570°(1058°F) Low content trace elements.
Largely insensitive to long-term embrittlement.
Suitable for chemical apparatus engineering for the welding of gasification, heavy-duty boile and super-heater fabrication and hot steam pipes.
Base materials:
13CrMo 4-5 (AISI/AWS A182-F 11&12), GS-22 CrMo 5-4.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - T Phoenix Cr2Mo SC E9018 3.2mm 5.0kg
Low Alloy Steel Covered Electrode Classification: E9018-B3H4R
Suited for the welding of 2.25Cr-1Mo low alloyed and creep resistant steels in boiler, tank, and pipeline etc.
Base materials:
10 CrMo 9-10. 12 CrMo 9-10, 10 CrSiMoV 7, 15CrMoV 5-10, SA335Gr.P22, SA217Gr. Wc9
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - T Phoenix CrMo 9 V Ni E9015 3.2mm 5.3kg
Steel Covered Electrode, Low alloyed
Classification: E9015-B91Basic-covered Cr Mo Ni V Nb alloyed electrode
Good welding characteristics in all position work, high-temperature weld metal of identical composition
For quenched and tempered 9% chromium steel, in particular P91/T91 according to AWS.
Preheating and interpass temperature shall be 200° and under 280° Cool till to room temperature before PWHT, for which the heating and cooling rate shall be 100°/hr.
Base materials:
X10CrMoVNb9 - 1 (1.4903), A213 - T91, A335 - P91
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode -Thermanit NiMo 100 E10018 3.2mm 4.2kg
Stick electrode, low-alloyed, basic
Classification: E10018-D2 H4Basic covered MnNiMo alloyed electrode. Very low H2-content ≤4 mI/11g; extremely high resistance to cracking and high toughness at temperatures as Iow as -40 °c (-40 °F).
For creep resistant steels and cast steel grades, valves, and oil tools according to sour gas specification; post-weld stress-relieving according to the parent metal.
Base materials:
GS-30 CrMo V64,
Steels acc. ASTM A 487-4Q; AISI 4130
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode -Thermanit Chromo 9V Mod MMAW 2.5mm 4.4kg
Stick electrode, basic coated, creep resistant
Classification: E9015-B9H4RThe basic coated CrMoVNB alloyed electrode is specially designed for welding of creep resistant tempered martensitic 9% Cr steels used for turbine and boiler fabrication in thermal power plants as well as in the chemical industry.
Thermanit Chromo 9 V Mod provides good welding characteristics in all positions except vertical down, a stable arc, low spattering, good slag detachability and excellent striking and re-striking properties.
The chemical composition is optimised in order to provide a high creep resistant and ductile weld metal and meets the requirement for restricted Mn + Ni content (≤ 1 wt. %). It is characterised by low hydrogen content and low level of trace elements.
This electrode has a half-synthetic cover concept.
Base materials:
Modified 9Cr-1Mo steels like 1.4903, X10CrMoVNb9-1, GX12CrMoVNbN9-1, ASTM Grade 91
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler Stick Electrode - FOX CEL 85 E8010 MMAW 4.0mm 9.2kg
Cellulosic stick electrode, for vertical-down welding, pipe welding
Classification: E8010Cellulose electrode for vertical-down welding of high strength large diameter pipelines. Highly economical compared with conventional vertical-up welding. Especially recommended for hot passes, filler and cover layers.
BÖHLER FOX CEL 85 is one of the most popular cellulosic electrode which meets all the exacting demands of the field welding of cross country pipelines extremely well.
Welding is easy also at difficult weather conditions. It ensures highest joint weld quality down to temperatures of –40 °C. BÖHLER FOX CEL 85 can be used in sour gas applications (HIC-Test acc. NACE TM-02-84). Test values for SSC-test are available too.
Base materials:
L415NB - L485NB, L415MB - L485MB API Spec. 5 L: X 56, X 60, X 65, X 70
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX CEL+ E6010 MMAW 4.0mm 8.5kg
Cellulosic stick electrode, for vertical down welding, pipe welding
Classification: E6010Cellulose electrode for vertical-down welding of large diameter pipelines. Especially recommended for root pass welding on D.C. positive polarity in the vertical down and vertical up welding positions.
Apart from its good welding and gap bridging characteristics Bohler FOX CEL+ provides a powerful arc that deposits well penetrated, smooth root passes with high travel speeds as well as high safety against the formation of piping or hollow bead and undercut.
BÖHLER FOX CEL+ can be used in sour gas applications (HIC-Test acc. to NACE TM-02-84). Test values for SSC-test are available too.
Base materials:
S235JR, S275JR, S235J2G3, S275J2G3, S355J2G3, P235GH, P265GH, P355T1, P235T2- P355T2, L210NB – L390NB, L290MB – L390MB, P235G1TH, P255G1TH root pass up to L555NB, L555MB
API Spec. 5 L: A, B, X 42, X 46, X 52, X 56, Root pass up to X 80
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta P5 E309MO MMAW 4.0mm 5.4kg
Stick electrode, high-alloyed, stainless, special applications
Classification: E309MO L-17Avesta P5 is a high-alloy low carbon electrode designed for welding dissimilar joints between stainless and mild or low-alloy steels. It can also be used for overlay welding on mild steel, providing an 18 Cr 8 Ni 2 Mo deposit from the very first layer.
Superior to 316L. When used for overlay welding on mild steel a corrosion resistance equivalent to that of 1.4401/ASTM 316 is obtained already in the first layer.
Base materials:
High-alloy low carbon electrode for surfacing unalloyed steel, joint welding molybdenum alloyed stainless steel to unalloyed steel and for welding clad material.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta 316/SKR MMAW 4.0mm 5.4kg
Stick electrode, high-alloyed
Classification: E316L-17Cr-Ni-Mo electrode for all position welding to ASTM 316 and 316L stainless steel.
Weld metal features a good resistance against intergranular corrosion ( IGC ASTM A262 Practice E )
Base materials:
Outokumpu 4436, 4432, 4429, 4571; EN 1.4436, 1.4432, 1.4429, 1.4571; ASTM 316, 316L, S31653, 316Ti; BS 316S33, 316S3, 316S63, 320S31; NF Z7 CND 18-12-03, Z3 CND 17-12-03, Z3 CND 17-12-Az, Z6 CND 17-12; SS 2343, 2353, 2375, 2350.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Avesta 309L MMAW 4.0mm 5.4kg
Stick electrode, Rutile, High-alloyed, Chemical resistant
Classification: E309L-17Avesta 309L is a high-alloy low carbon electrode designed for welding dissimilar joints between stainless and mild or low-alloy steels. The electrode is well suited as a buffer layer when overlay welding on mild steels, providing an 18 Cr 8 Ni deposit from the first layer.
Avesta 309L can also be used for welding some high-temperature steels, such as 1.4833/ASTM 309S. Corrosion resistance: Superior to 308L. When used for overlay welding on mild steel a corrosion resistance equivalent to that of 1.4301/ASTM 304 is obtained already in the first layer.
Base materials:
High-alloy low carbon electrode for surfacing unalloyed steel, joint welding molybdenum-alloyed stainless steel to unalloyed steel and for welding clad material.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S EV Pipe-1 E7016 4.0mm 5.0kg
Basic stick electrode for vertical-up welding, pipe welding
Classification: E7016-1H4RBohler FOX EV PIPE is a basic coated electrode, suited for positional welding of root passes using DC ( – ) as well as for filler and cover passes of pipes, tubes, and plates on DC ( + ), or even AC. Good gap bridging ability together with easy slag removal ensures minimum grinding.
Weld- metal toughness is available down to -45°C. BÖHLER FOX EV PIPE offers considerable time savings against AWS E7018 type electrodes when welding root passes due to increased travel speeds.
Also the use of dia. 3.2 mm is possible for root passes in case of wall thicknesses of 8 mm and more.
Bohler FOX EV PIPE can be used in sour gas applications (HIC-Test acc. to NACE TM-02-84). Test values for SSC-test are available too.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX EV 50 E7018 H4R 4.0mm 5.0kg
Stick Electrode, Unalloyed basic
Classification: E7018 H4RBasic covered electrode with very good welding characteristics including out of position work.
Weld metal recovery about 115%*.
Crack-free weld metal when welding high-carbon steels.
Suitable for use in tank construction, boiler and pressure vessel manufacturer, apparatus engineering, vehicle manufacture, offshore applications and ship building.
Base materials:
S235JRG2 – S355J2, E295, E335, C35; boiler steels P235GH, P265 GH, P295GH, P355GH; fine grained structural steels up to S420N; shipbuilding steels A, B, D, E; offshore steels; pipe steels P265, P295, L290NB – L415NB, L290MB – L415MB, X42 – X56; cast steels GS-38, GS-45, GS-52; ageing resistant steels Ast35 – Ast52; SA 516 Gr 60, 65, 70; SA333 Gr 6.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S 308L-16 MMAW 4.0mm 4.1kg
Stick electrode, low-alloyed
Classification: E308L-16Bohler Fox S 308L-16 is a Cr-Ni electrode for all position welding of 1.4301/ASTM 304 types stainless steel. corrosion resistance: very good under fairly severe conditions, e.g. in oxidation acids and cold or dilute reducing acids.
Base materials:
ASTM 304, 304L; BS304S31, 304S11, 304S61; SS2333, 2352
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S 316L-16 MMAW 4.0mm 4.1kg
Stick electrode, high-alloyed
Classification: E316L-16Low carbon, core wire alloyed, austenitic stick electrode with rutile coating. For application in all branches of industry where same-type steels, including higher carbon-seels and feritic 13% chrome steels are welded. Special fine welding properties, excellent welding with AC power and high resistance to hot cracking in the weld metal are features of this product.
Resists intergranular corrosion up to +400°C.
Base materials:
ASTM 316 - 316L-S31653; SS 2343-2353-2375; BS316S33,316S13
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX S OHV E6013 MMAW 4.0mm 5.0kg
Stick electrode, Rutile - cellulosic, unalloyed
Classification: E6013Rutile-cellulosic electrode with good weldability in all positions including vertical down. Most popular E6013 type, suitable for small transformers with low OCV. Very good operating characteristics. The Slag Covering and its removability are good. Flexible coating, good for tack welding.
Versatile applications in structural welding, automotive fabrication, boiler and tank welding, and in shipbuilding. Also suitable for galvanized components.
Base materials:
Steels up to a yield strength of 380 N/mm2 (52 ksi)
S275JR, S235J0G3 - S355J0G3, P235GH, P265GH, P255NH, P235T1, P355T1, P235T2-P355T2, P235G1TH, P255G1TH, L210 - L360NB, L290MB, S235JRS1 - S235J0S1, S235JRS2 - S235J0S2
ASTM A36 a. A53 Gr. all; A106 Gr. A, B, C A 135 Gr. A, B; A283 Gr. A, B, C, D; A366; A285
Gr. A, B, C; A500 Gr. A, B, C; A570 Gr. 30, 33, 36, 40, 45; A607 Gr. 45; A668 Gr. A, B; A907
Gr. 30, 33, 36, 40; A935 Gr.45; A936 Gr. 50; API 5 L Gr. B, X42 - X52
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - FOX SAS 2-A FCAW E347 4.0mm 5.2kg
Flux-cored wire, high-alloyed, stainless
Classification: E347-17Rutile coated core wire alloyed, stabilised austenitic electrode, mainly for Ti or Nb stabilised 1.4541 / 321 / 347 CrNi-steel grades.
Designed for first class weld seems and easy handling on AC or DC. High current carrying capacity, minimum spatter formation, self-releasing slag, smooth and clean weld profile, safety against formation of porosity due to moisture resistant coating.
The fully alloyed core wire ensures the most reliable corrosion resistance. Resistant to intergranular corrosion up to +400 °C.
Base materials:
1 1.4550 X6CrNiNb18-10, 1.4541 X6CrNiTi18-10, 1.4552 GX5CrNiNb19-11, 1.4301 X5CrNi18-10, 1.4312 GX10CrNi18-8, 1.4546 X5CrNiNb18-10, 1.4311 X2CrNiN18-10, 1.4306 X2CrNi19-11
AISI 347, 321,302, 304, 304L, 304LN, ASTM A296 Gr. CF 8 C, A157 Gr. C9, A320 Gr. B8C or D
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode - Phoenix Spezial D MMAW 4.0mm 5.1kg
Stick electrode, Unalloyed basic
Basic double-coated electrode with excellent weldability in all position except vertical down. Especially suited for out-of-position welding thanks to the weld controlled arc.
Excellent root penetration. Good suitability for welding in AC.
Minimum spatter loss, very easy slag removal with uniform beads. Well suited for lower OCV power sources. Low hydrogen content in the weld deposit (HD < 10 ml/100 g deposit)
Base materials:
Steels up to a yield strength of 420 MPa (60 ksi)
S235JR-S355JR, S235JO-S355JO, S235J2-S355J2, S275N-S420N, S275M-S420M, P235GHP355GH, P355N, P285NH-P420NH, P195TR1-P265TR1, P195TR2-P265TR2, P195GH-P265GH, L245NB-L415NB, L245MB-L415MB, GE200-GE240
ASTM A 106 Gr. A, B, C; A 181 Gr. 60, 70; A 283 Gr. A, C; A 285 Gr. A, B, C; A 414 Gr. A, B, C, D, E, F, G; A 501 Gr. B; A 516 Gr. 55, 60, 65, 70; A 573 Gr. 58, 65, 70; A 588 Gr. A, B; A 633 Gr. A, C, D; A 662 Gr. A, B, C; A 678 Gr. A, B; A 711 Gr. 1013; API 5 L Gr. B, X42, X52, X56, X60
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Stick Electrode -Thermanit NiMo 100 E10018 4.0mm 5.7kg
Stick electrode, low-alloyed, basic
Classification: E10018-D2 H4Basic covered MnNiMo alloyed electrode. Very low H2-content ≤4 mI/11g; extremely high resistance to cracking and high toughness at temperatures as Iow as -40 °c (-40 °F).
For creep resistant steels and cast steel grades, valves, and oil tools according to sour gas specification; post-weld stress-relieving according to the parent metal.
Base materials:
GS-30 CrMo V64,
Steels acc. ASTM A 487-4Q; AISI 4130
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler TIG Rod - Avesta 2205 GTAW ER2209 ER90S-B9 - 1.6mm 5Kg
TIG rod, high-alloyed, high corrosion resistant
Classification: ER2209Avesta 2205 is primarily designed for welding the duplex grade Outokumpu 2205 and similar but it can also be used for SAF 2304 type of steels. Avesta 2205 provides a ferritic-austenitic weldment that combines many of the good properties of both ferritic and austenitic stainless steel.
Welding without filler metal (i.e. TIG-dressing) is not allowed since the ferrite content will increase drastically and both mechanical and corrosion properties will be negatively affected. Structure: Austenite with 45 – 55 % ferrite. Scaling temperature: Approx. 850 °C (air).
Corrosion resistance: Very good resistance to pitting and stress corrosion cracking in chloride-containing environments
Base materials:
Similar duplex stainless steels, also combinations of duplex, ferritic and austenitic steels
1.4462 X2CrNiMoN22-5-3, 1.4362 X2CrNiN23-4, 1.4462 X2CrNiMoN22-5-3 with 1.4583 X10CrNiMoNb18-12, 1.4462 X2CrNiMoN22-5-3 with P235GH/ P265GH, S255N, P295GH, S355N, 16Mo3 UNS S31803, S32205
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - Avesta 308L/MVR MMAW E308L - 1.6mm 5Kg
Welding Wire TIG
Classification: E308L
Part No: BOH-ER308L-1.6-79967Is designed for welding austenitic stainless steel type 19Cr 10Ni or similar.
The wire is also suitable for welding titanium and niobium stabilised steels such as ASTM 321 and ASM 347 in cases where the construction is used at temperatures not exceeding 400°C.
Base materials:
Outokumpu 4301, 4307, 4311, 4541; EN 1.4301, 1.4307, 1.4311, 1.4541; ASTM 304, 304L, 304LN, 321; BS 304S31, 304S11, 304S61, 321S31; NF Z7 CN 18-09, Z3 CN 18-10, Z3 CN 18-10 Az, Z6 CNT 18-10; SS 2333, 2352, 2371, 2337.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - Avesta 316L/SKR GTAW ER316L - 1.6mm 5Kg
TIG welding wire Classification: ER316L
Designed for welding austenitic stainless steel type 17Cr 12 Ni 2.50 Mo or similar. The filler metal is also suitable for welding titanium and niobium stabilised steels
Base materials:
Outokumpu 4436, 4432, 4429, 4571; EN 1.4436, 1.4432, 1.4429, 1.4571; ASTM 316, 316L, S31653, 316Ti, BS 316S33, 316S13, 316S63, 320S31, NF Z7 CND 18-12-03, Z3 CND 17-12-03, Z3 CND 17-12 Az, Z6 CND 17-12; SS 2343, 2353, 2375, 2350.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - SAS 2-IG GTAW TIG High Alloyed ER347 - 1.6mm 5Kg
TIG rod, high-alloyed, stainless Classification: ER347
GTAW rod of type W 19 9 Nb / ER 347 engineered to a very precise analysis to create a weld deposit of high purity, superior hot cracking a corrosion resistance.
CVN toughness down to –196 °C, resistant to intergranular corrosion up to +400 °C.
Base materials:
1.4550 X6CrNiNb18-10, 1.4541 X6CrNiTi18-10, 1.4552 G-X5CrNiNb19-11, 1.4301 X5CrNi18-10, 1.4312 GX10CrNi18-8, 1.4546 X5CrNiNb18-10, 1.4311 X2CrNiN18-10, 1.4306 X2CrNi19-11, AISI 347, 321,302, 304, 304L, 304LN; ASTM A296 Gr. CF 8 C, A157 Gr. C9, A320 Gr. B8C or DFor further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler TIG Rod - T Union GT Cr2Mo GTAW Class ER90S-B3 1.6mm 5Kg
Low Alloyed Steel GTAW Rod/Wire
Classification: ER90S-B3GTAW solid rod for the welding of 2.25Cr-1Mo low alloyed and creep resistant steels.
Suitable for welding of low alloyed and creep resistant steels in boiler, tank, and pipeline.
Base materials:
10 CrMo 9-10. 12 CrMo 9-10, 10 CrSiMoV 7, 15CrMoV 5-10, SA335Gr.P22, SA217Gr. Wc9
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - T Union GT Cr1Mo GTAW Class ER80S-B2 1.6mm 5Kg
Low Alloyed Steel GTAW Rod/Wire
Classification: ER80S-B2GTAW solid wire electrode for the welding of 1.25Cr-0.5Mo low alloyed and creep resistant steels.
Suitable for manufacturing creep-resistant steels in boiler, tank, and pipeline.
Base materials:
L13CrMo 4-5 (AISI/AWS A182-F 11&12), GS-22 CrMo 5-4, A355Gr. P11 and P12.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - Bohler S EML 5 GTAW ER70S-3 1.6mm 5Kg
TIG rod, unalloyed Classification: ER70S-3
Copper Coated mild steel GTAW rod with low Si content ~ 0.6% w.t and provide sufficient deoxidation. BOHLER S EML 5 is used for high integrity weld with excellent x-ray quality, It is suited for root pass welding and multi pass welding.
This filler metal particularly is used for joint welds that are subjected to enamelling or galvanisihing.
Base materials:
Steels up to a yield strength of 460 MPa (67 ksi)
S235J2G3 - S355J2G3, E360, P235T1-P355T1, P235G1TH, L210, L290MB, P255G1TH, P235GH, P265GH, P295GH, P310GH, P255NH, S235JRS1 - S235J4S, S355G1S - S355G3S, S255N - S385N, P255NH-P385NH, GE200-GE260
ASTM A27 a. A36 Gr. all; A214; A242 Gr.1-5; A266 Gr. 1, 2, 4; A283 Gr. A, B, C, D; A285 Gr. A, B, C; A299 Gr. A, B; A328; A366; A515 Gr. 60, 65, 70; A516 Gr. 55; A570 Gr. 30, 33, 36, 40, 45; A 572 Gr. 42, 50; A606 Gr. all; A607 Gr. 45; A656 Gr. 50, 60; A668 Gr. A, B; A907 Gr. 30, 33, 36, 40; A841; A851 Gr. 1, 2; A935 Gr.45; A936 Gr. 50; API 5 L Gr. B, X42-X60
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - Bohler S EMK 6 GTAW ER70S-6 1.6mm 5Kg
TIG rod, unalloyed
Classification: ER70S-6GTAW rod with the high silicon content. The welding rod is suited for joints in boiler and vessel fabrication as well as in structural steel engineering.
BOHLER EMK 6 can be used in sour gas applications (HIC-Test acc. to NACE TM-02-84). Test values for SSC-test are available.
Base materials:
Steels up to a yield strength of 420 MPa (60 ksi)
S235J2G3-S355J2G3, E360, P235T1-P355T1, P235G1TH, L210, L290MB, P255G1TH, P235GH, P265GH, P295GH, P310GH, P255NH, S235JRS1-S235J4S, S355G1S-S355G3S, S255N-S385N, P255NH-P385NH, GE200-GE260
ASTM A27 a. A36 Gr. all; A214; A 242 Gr.1-5; A266 Gr. 1, 2, 4; A283 Gr. A, B, C, D; A285 Gr. A, B, C; A299 Gr. A, B; A328; A366; A515 Gr. 60, 65, 70; A516 Gr. 55; A570 Gr. 30, 33, 36, 40, 45; A 572 Gr. 42, 50; A606 Gr. all; A607 Gr. 45; A656 Gr. 50, 60; A668 Gr. A, B; A907 Gr. 30, 33, 36, 40; A841; A851 Gr. 1, 2; A935 Gr.45; A936 Gr. 50; API 5 L Gr. B, X42 – X60
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler TIG Rod - Avesta 2205 GTAW ER2209 ER90S-B9 - 2.0mm 5Kg
TIG rod, high-alloyed, high corrosion resistant
Classification: ER2209Avesta 2205 is primarily designed for welding the duplex grade Outokumpu 2205 and similar but it can also be used for SAF 2304 type of steels. Avesta 2205 provides a ferritic-austenitic weldment that combines many of the good properties of both ferritic and austenitic stainless steel.
Welding without filler metal (i.e. TIG-dressing) is not allowed since the ferrite content will increase drastically and both mechanical and corrosion properties will be negatively affected. Structure: Austenite with 45 – 55 % ferrite. Scaling temperature: Approx. 850 °C (air).
Corrosion resistance: Very good resistance to pitting and stress corrosion cracking in chloride-containing environments
Base materials:
Similar duplex stainless steels, also combinations of duplex, ferritic and austenitic steels
1.4462 X2CrNiMoN22-5-3, 1.4362 X2CrNiN23-4, 1.4462 X2CrNiMoN22-5-3 with 1.4583 X10CrNiMoNb18-12, 1.4462 X2CrNiMoN22-5-3 with P235GH/ P265GH, S255N, P295GH, S355N, 16Mo3 UNS S31803, S32205
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - Avesta 316L/SKR GTAW ER316L - 2.0mm 5Kg
TIG welding wire Classification: ER316L
Designed for welding austenitic stainless steel type 17Cr 12 Ni 2.50 Mo or similar. The filler metal is also suitable for welding titanium and niobium stabilised steels
Base materials:
Outokumpu 4436, 4432, 4429, 4571; EN 1.4436, 1.4432, 1.4429, 1.4571; ASTM 316, 316L, S31653, 316Ti, BS 316S33, 316S13, 316S63, 320S31, NF Z7 CND 18-12-03, Z3 CND 17-12-03, Z3 CND 17-12 Az, Z6 CND 17-12; SS 2343, 2353, 2375, 2350.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - T Union GT Cr2Mo GTAW Class ER90S-B3 2.0mm 5Kg
Low Alloyed Steel GTAW Rod/Wire
Classification: ER90S-B3GTAW solid rod for the welding of 2.25Cr-1Mo low alloyed and creep resistant steels.
Suitable for welding of low alloyed and creep resistant steels in boiler, tank, and pipeline.
Base materials:
10 CrMo 9-10. 12 CrMo 9-10, 10 CrSiMoV 7, 15CrMoV 5-10, SA335Gr.P22, SA217Gr. Wc9
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - T Union GT Cr1Mo GTAW Class ER80S-B2 2.0mm 5Kg
Low Alloyed Steel GTAW Rod/Wire
Classification: ER80S-B2GTAW solid wire electrode for the welding of 1.25Cr-0.5Mo low alloyed and creep resistant steels.
Suitable for manufacturing creep-resistant steels in boiler, tank, and pipeline.
Base materials:
L13CrMo 4-5 (AISI/AWS A182-F 11&12), GS-22 CrMo 5-4, A355Gr. P11 and P12.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - Bohler S EML 5 GTAW ER70S-3 2.0mm 5Kg
TIG rod, unalloyed Classification: ER70S-3
Copper Coated mild steel GTAW rod with low Si content ~ 0.6% w.t and provide sufficient deoxidation. BOHLER S EML 5 is used for high integrity weld with excellent x-ray quality, It is suited for root pass welding and multi pass welding.
This filler metal particularly is used for joint welds that are subjected to enamelling or galvanisihing.
Base materials:
Steels up to a yield strength of 460 MPa (67 ksi)
S235J2G3 - S355J2G3, E360, P235T1-P355T1, P235G1TH, L210, L290MB, P255G1TH, P235GH, P265GH, P295GH, P310GH, P255NH, S235JRS1 - S235J4S, S355G1S - S355G3S, S255N - S385N, P255NH-P385NH, GE200-GE260
ASTM A27 a. A36 Gr. all; A214; A242 Gr.1-5; A266 Gr. 1, 2, 4; A283 Gr. A, B, C, D; A285 Gr. A, B, C; A299 Gr. A, B; A328; A366; A515 Gr. 60, 65, 70; A516 Gr. 55; A570 Gr. 30, 33, 36, 40, 45; A 572 Gr. 42, 50; A606 Gr. all; A607 Gr. 45; A656 Gr. 50, 60; A668 Gr. A, B; A907 Gr. 30, 33, 36, 40; A841; A851 Gr. 1, 2; A935 Gr.45; A936 Gr. 50; API 5 L Gr. B, X42-X60
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - Bohler S EMK 6 GTAW ER70S-6 2.0mm 5Kg
TIG rod, unalloyed
Classification: ER70S-6GTAW rod with the high silicon content. The welding rod is suited for joints in boiler and vessel fabrication as well as in structural steel engineering.
BOHLER EMK 6 can be used in sour gas applications (HIC-Test acc. to NACE TM-02-84). Test values for SSC-test are available.
Base materials:
Steels up to a yield strength of 420 MPa (60 ksi)
S235J2G3-S355J2G3, E360, P235T1-P355T1, P235G1TH, L210, L290MB, P255G1TH, P235GH, P265GH, P295GH, P310GH, P255NH, S235JRS1-S235J4S, S355G1S-S355G3S, S255N-S385N, P255NH-P385NH, GE200-GE260
ASTM A27 a. A36 Gr. all; A214; A 242 Gr.1-5; A266 Gr. 1, 2, 4; A283 Gr. A, B, C, D; A285 Gr. A, B, C; A299 Gr. A, B; A328; A366; A515 Gr. 60, 65, 70; A516 Gr. 55; A570 Gr. 30, 33, 36, 40, 45; A 572 Gr. 42, 50; A606 Gr. all; A607 Gr. 45; A656 Gr. 50, 60; A668 Gr. A, B; A907 Gr. 30, 33, 36, 40; A841; A851 Gr. 1, 2; A935 Gr.45; A936 Gr. 50; API 5 L Gr. B, X42 – X60
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler TIG Rod - Thermanit MTS 3 GTAW ER90S-B9 - 2.4mm 10Kg
TIG rod, high-alloyed, creep resistant
Classification: ER90S-B9High temperature resistant, resistant to scaling up to 600 °C (1112 °F). Suited for joining and surfacing applications with quenched and tempered 9 % Cr steels, particularly for matching high temperature resistant parent metal T91 / P91 according to ASTM.
Base materials:
1.4903 – X10CrMoVNb9-1; ASTM A 199 Gr. T91; A 355 Gr. P91 (T91); A 213/213M Gr. T91
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - Avesta 2205 GTAW ER2209 ER90S-B9 - 2.4mm 5Kg
TIG rod, high-alloyed, high corrosion resistant
Classification: ER2209Avesta 2205 is primarily designed for welding the duplex grade Outokumpu 2205 and similar but it can also be used for SAF 2304 type of steels. Avesta 2205 provides a ferritic-austenitic weldment that combines many of the good properties of both ferritic and austenitic stainless steel.
Welding without filler metal (i.e. TIG-dressing) is not allowed since the ferrite content will increase drastically and both mechanical and corrosion properties will be negatively affected. Structure: Austenite with 45 – 55 % ferrite. Scaling temperature: Approx. 850 °C (air).
Corrosion resistance: Very good resistance to pitting and stress corrosion cracking in chloride-containing environments
Base materials:
Similar duplex stainless steels, also combinations of duplex, ferritic and austenitic steels
1.4462 X2CrNiMoN22-5-3, 1.4362 X2CrNiN23-4, 1.4462 X2CrNiMoN22-5-3 with 1.4583 X10CrNiMoNb18-12, 1.4462 X2CrNiMoN22-5-3 with P235GH/ P265GH, S255N, P295GH, S355N, 16Mo3 UNS S31803, S32205
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - Avesta 308L/MVR MMAW E308L - 2.4mm 5Kg
Welding Wire TIG
Classification: E308L
Part No: BOH-ER308L-1.6-79967Is designed for welding austenitic stainless steel type 19Cr 10Ni or similar.
The wire is also suitable for welding titanium and niobium stabilised steels such as ASTM 321 and ASM 347 in cases where the construction is used at temperatures not exceeding 400°C.
Base materials:
Outokumpu 4301, 4307, 4311, 4541; EN 1.4301, 1.4307, 1.4311, 1.4541; ASTM 304, 304L, 304LN, 321; BS 304S31, 304S11, 304S61, 321S31; NF Z7 CN 18-09, Z3 CN 18-10, Z3 CN 18-10 Az, Z6 CNT 18-10; SS 2333, 2352, 2371, 2337.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - Avesta 316L/SKR GTAW ER316L - 2.4mm 5Kg
TIG welding wire Classification: ER316L
Designed for welding austenitic stainless steel type 17Cr 12 Ni 2.50 Mo or similar. The filler metal is also suitable for welding titanium and niobium stabilised steels
Base materials:
Outokumpu 4436, 4432, 4429, 4571; EN 1.4436, 1.4432, 1.4429, 1.4571; ASTM 316, 316L, S31653, 316Ti, BS 316S33, 316S13, 316S63, 320S31, NF Z7 CND 18-12-03, Z3 CND 17-12-03, Z3 CND 17-12 Az, Z6 CND 17-12; SS 2343, 2353, 2375, 2350.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - SAS 2-IG GTAW TIG High Alloyed ER347 - 2.4mm 5Kg
TIG rod, high-alloyed, stainless Classification: ER347
GTAW rod of type W 19 9 Nb / ER 347 engineered to a very precise analysis to create a weld deposit of high purity, superior hot cracking a corrosion resistance.
CVN toughness down to –196 °C, resistant to intergranular corrosion up to +400 °C.
Base materials:
1.4550 X6CrNiNb18-10, 1.4541 X6CrNiTi18-10, 1.4552 G-X5CrNiNb19-11, 1.4301 X5CrNi18-10, 1.4312 GX10CrNi18-8, 1.4546 X5CrNiNb18-10, 1.4311 X2CrNiN18-10, 1.4306 X2CrNi19-11, AISI 347, 321,302, 304, 304L, 304LN; ASTM A296 Gr. CF 8 C, A157 Gr. C9, A320 Gr. B8C or DFor further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler TIG Rod - T Union GT Cr2Mo GTAW Class ER90S-B3 2.4mm 5Kg
Low Alloyed Steel GTAW Rod/Wire
Classification: ER90S-B3GTAW solid rod for the welding of 2.25Cr-1Mo low alloyed and creep resistant steels.
Suitable for welding of low alloyed and creep resistant steels in boiler, tank, and pipeline.
Base materials:
10 CrMo 9-10. 12 CrMo 9-10, 10 CrSiMoV 7, 15CrMoV 5-10, SA335Gr.P22, SA217Gr. Wc9
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - CN 13.4-IG GTAW - ER410NiMo 2.4mm 5Kg
TIG rod, high-alloyed, stainless Classification: ER410NiMo
Part No: BOH-ER410NiMo-2.4-12886
GTAW rod of low-carbon type 13 % Cr 4 % Ni suited for soft-martensitic steels like 1.4313 / CA 6 NM.
Designed with precisely tuned alloying composition creating a weld deposit featuring very good ductility, CVN toughness and crack resistance despite its high strength.
For applications like hydro- and steam turbines, corrosion resistant against water and steam.
Base materials:
1.4317 GX4CrNi13-4, 1.4313 X3CrNiMo13-4, 1.4407 GX5CrNiMo13-4, 1.4414 GX4CrNiMo13-4 ACI Gr. CA6NM
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - T Union GT Cr1Mo GTAW Class ER80S-B2 2.4mm 5Kg
Low Alloyed Steel GTAW Rod/Wire
Classification: ER80S-B2GTAW solid wire electrode for the welding of 1.25Cr-0.5Mo low alloyed and creep resistant steels.
Suitable for manufacturing creep-resistant steels in boiler, tank, and pipeline.
Base materials:
L13CrMo 4-5 (AISI/AWS A182-F 11&12), GS-22 CrMo 5-4, A355Gr. P11 and P12.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - Bohler S EML 5 GTAW - ER70S-3 2.4mm 5Kg
TIG rod, unalloyed Classification: ER70S-3
Copper Coated mild steel GTAW rod with low Si content ~ 0.6% w.t and provide sufficient deoxidation. BOHLER S EML 5 is used for high integrity weld with excellent x-ray quality, It is suited for root pass welding and multi pass welding.
This filler metal particularly is used for joint welds that are subjected to enamelling or galvanisihing.
Base materials:
Steels up to a yield strength of 460 MPa (67 ksi)
S235J2G3 - S355J2G3, E360, P235T1-P355T1, P235G1TH, L210, L290MB, P255G1TH, P235GH, P265GH, P295GH, P310GH, P255NH, S235JRS1 - S235J4S, S355G1S - S355G3S, S255N - S385N, P255NH-P385NH, GE200-GE260
ASTM A27 a. A36 Gr. all; A214; A242 Gr.1-5; A266 Gr. 1, 2, 4; A283 Gr. A, B, C, D; A285 Gr. A, B, C; A299 Gr. A, B; A328; A366; A515 Gr. 60, 65, 70; A516 Gr. 55; A570 Gr. 30, 33, 36, 40, 45; A 572 Gr. 42, 50; A606 Gr. all; A607 Gr. 45; A656 Gr. 50, 60; A668 Gr. A, B; A907 Gr. 30, 33, 36, 40; A841; A851 Gr. 1, 2; A935 Gr.45; A936 Gr. 50; API 5 L Gr. B, X42-X60
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - Bohler S EMK 6 GTAW ER70S-6 2.4mm 5Kg
TIG rod, unalloyed
Classification: ER70S-6GTAW rod with the high silicon content. The welding rod is suited for joints in boiler and vessel fabrication as well as in structural steel engineering.
BOHLER EMK 6 can be used in sour gas applications (HIC-Test acc. to NACE TM-02-84). Test values for SSC-test are available.
Base materials:
Steels up to a yield strength of 420 MPa (60 ksi)
S235J2G3-S355J2G3, E360, P235T1-P355T1, P235G1TH, L210, L290MB, P255G1TH, P235GH, P265GH, P295GH, P310GH, P255NH, S235JRS1-S235J4S, S355G1S-S355G3S, S255N-S385N, P255NH-P385NH, GE200-GE260
ASTM A27 a. A36 Gr. all; A214; A 242 Gr.1-5; A266 Gr. 1, 2, 4; A283 Gr. A, B, C, D; A285 Gr. A, B, C; A299 Gr. A, B; A328; A366; A515 Gr. 60, 65, 70; A516 Gr. 55; A570 Gr. 30, 33, 36, 40, 45; A 572 Gr. 42, 50; A606 Gr. all; A607 Gr. 45; A656 Gr. 50, 60; A668 Gr. A, B; A907 Gr. 30, 33, 36, 40; A841; A851 Gr. 1, 2; A935 Gr.45; A936 Gr. 50; API 5 L Gr. B, X42 – X60
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler TIG Rod - Bohler Ni 1-IG GTAW - Class ER80NI-1 2.4mm 5Kg
TIG rod, low alloyed, cryogenic application
Classification: ER80NI-1Ni-alloyed GTAW rod for welding of offshore pipe work and similar high integrity applications. High impact properties down to –50 °C. Test values for SSC-test are available.
Base materials:
Cryogenic fine-grained steels and high strength steels up to 460 MPa yield strength. S275N-S460N, S275NL-S460NL, S275M-S460M, S275ML-S460ML, P355N, P355NH, P460N, P460NH, P275NL1-P460NL1, P275NL2-P460NL2, L360NB, L415NB, L360MB-L450MB, L360QBL450QB ASTM A 203 Gr. D, E; A 350 Gr. LF1, LF2, LF3; A 420 Gr. WPL3, WPL6; A 516 Gr. 60, 65, 70; A 572 Gr. 42, 50, 55, 60, 65; A 633 Gr. A, D, E; A 662 Gr. A, B, C; A 707 Gr. L1, L2, L3; A 738 Gr. A; A 841 A, B, C; API 5 L X52, X60, X65, X52Q, X60Q, X65Q
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
Bohler Welding Flux - UV C 401 Flux (AB 1 Basic Neutral) 25kg Bag
BOHLER WELDING - UV C 401 Flux (AB 1 Basic Neutral)
SAW flux, aluminate-basic type
Classification: SA AB 1 67 AC H5
Part No: BOH-UVC401-PB25
UV C 401 is an agglomerated flux of aluminate-basic type for joining and surfacing applications with general-purpose structural steels, boiler and pipe steels.
The flux is characterised by low Silicon and Moderate manganese pick-up.
The welding characteristics are good producing a smooth weld bead with excellent slag detachability.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
Bohler Welding Flux - UV 401 TT Flux (PB25 Basic Neutral) 25kg Bag
BOHLER WELDING - UV 418 TT Flux (Basic Neutral)
SAW flux, fluoride-basic type
Classification: SA FB 1 56 AC H5
Part No: BOH-UVC418TT-PB25
UV C 418 TT-M is an agglomerated flux of fluoride basic type for joining and surfacing applications.
Mainly for multipass butt welding of medium and high strength fine grained and structural steels.
The flux can be used for tandem and multi wire welding with DC+ and AC.
Very good slag detachability and impact toughness of weld metal at low temperatures.
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
UTP Maintenance - Flux Cored Wire UTP AF 62222 MoPW - 1.2mm
Gas shielded flux-cored wire
Classification: ENiCrMo3T1-4The nickel-base-flux-cored wire UTP AF 6222 Mo PW is suitable for joining and surfacing on nickel-base materials of the same nature and on C and CrNi-steels as well as for cladding of C-steels, furthermore in high-temperature applications.
UTP AF 6222 Mo PW distinguishes by a hot cracking resistant and tough weld metal. It is suitable for operating temperatures up to 500°C and above 800°C. It must be noted that a slight decrease in ductility will occur if prolonged heat treatment is given within the temperature range of 550 – 800°C. UTP AF 6222 Mo PW provides excellent weldability out of position with stable and fine drop transfer. The weld seam is finely rippled and the transition from weld to base materials is regular and notch-free. The wide parameter range enables an application on different wall thicknesses.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance - Metal Cored Wire - UTP SK FNM4-G FCAW - 1.2mm
Gas shielded metal-cored wire
Classification: ENiFeT04-1Part No: BOH-ENiFeT04-1.2-54713
FeNi alloy with 4% Manganese designed for joining and surfacing of cast iron pieces. Can also be used for dissimilar welding between cast iron and steel.
Microstructure: Austenite
Machinability: Good Oxy-acetylene cutting: Cannot be flame cut
Deposit thickness: Depends upon application and procedure used
Shielding gas: Argon 98% + Oxygen 2% or Argon 100% or Argon 82%+ CO2 18%
Field of use: Repair work on cast iron components.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance - Metal Cored Wire UTP SK 255-O FCAW - 1.2mm
Open arc metal-cored wire Classification: FeCr-A9
Self-shielded cored wire designed to deposit an alloy resistant to high stress grinding abrasion with low impact. The deposits will readily show stress relief cracks.
Microstructure: Primary carbides and eutectic carbides in an austenitic matrix
Machinability: Grinding only
Oxy-acetylene cutting: Cannot be flame cut
Deposit thickness: 8 to 10 mm maximum in 2 to 3 layers
Field of use: Palm oil expeller screws, groundnut oil expeller screws, cement conveyors screws, catalytic pipes, dredge pump impellers, dredge cutters, shovel bucket teeth.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance Metal Cored UTP AF Robotic 600 FCAW - 1.2mm
Metal-cored wire, Gas Shielded
Classification: 1855-B5UTP AF ROBOTIC 600 is a seamless, chromium-alloyed, metal-cored wire for wear-resistant hardfacing applications on parts subject to a combination of pressure, impact and abrasion wear. Very good weldability in comparison to solid wires, good resistance to abrasion, minimised slag formation with easy slag removal.
Thanks to its constant wire feed and excellent weldability, this wire is especially suited for automated welding.
Field of use: Cutting tools, esp. cutting edges of presses in ceramic tiles production, jaw crushers, baffle plates.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Gas Shielded Metal Cored UTP AF Robotic 603 FCAW - 1.2mm
Gas-shielded metal-cored wire
Classification: 1855-B5Part No: BOH-ROBOTIC603-1.2-38747
UTP AF ROBOTIC 603 is a seamless, chromium-molybdenum-tungsten-vanadium-alloyed, metal-cored wire for abrasion and moderate stress-resistant surfacing applications up to 550°C.
Thanks to its constant wire feed and excellent weldability, this wire is especially suited for automated welding.
Application field:
Crushing hammers, bulldozer buckets, bucket teeth, hammers, cutting tools
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Gas Shielded Metal Cored UTP AF Robotic 352 FCAW - 1.2mm
Gas-shielded metal-cored wire
Classification: 1430-B5Part No: BOH-ROBOTIC352-1.2-38735
UTP AF ROBOTIC 352 is a seamless, low-alloyed metal-cored wire for surfacing medium-hard steels. Thanks to its constant wire feed and excellent weldability, this flux-cored wire is especially suitable for automated welding.
Application field:
Pulleys, chains, crawler rollers and gear wheels.
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
UTP Maintenance - Metal Cored Wire SK255-G FCAW Hardfacing - 1.6mm
Gas shielded metal cored wire
Part No: BOH-SK 255-G-1.6-47550Gas shielded cored wire designed to deposit an alloy resistant to high stress grinding abrasion with low impact. The deposits will readily show stress relief cracks.
Microstructure: Primary carbides and eutectic carbides in an austenitic matrix
Machinability: Grinding only
Oxy-acetylene cutting: Cannot be flame cut
Deposit thickness: 8 to 10 mm maximum in 2 to 3 layers
Shielding gas: Argon 98% + Oxygen 2%
Field of use: Palm oil expeller screws, groundnut oil expeller screws, cement conveyors screws, catalytic pipes, dredge pump impellers, dredge cutters, shovel bucket teeth.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance - Metal Cored Wire UTP SK 255-O FCAW - 1.6mm
Open arc metal-cored wire Classification: FeCr-A9
Self-shielded cored wire designed to deposit an alloy resistant to high stress grinding abrasion with low impact. The deposits will readily show stress relief cracks.
Microstructure: Primary carbides and eutectic carbides in an austenitic matrix
Machinability: Grinding only
Oxy-acetylene cutting: Cannot be flame cut
Deposit thickness: 8 to 10 mm maximum in 2 to 3 layers
Field of use: Palm oil expeller screws, groundnut oil expeller screws, cement conveyors screws, catalytic pipes, dredge pump impellers, dredge cutters, shovel bucket teeth.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance Metal Cored UTP AF Robotic 600 FCAW - 1.6mm
Metal-cored wire, Gas Shielded
Classification: 1855-B5UTP AF ROBOTIC 600 is a seamless, chromium-alloyed, metal-cored wire for wear-resistant hardfacing applications on parts subject to a combination of pressure, impact and abrasion wear. Very good weldability in comparison to solid wires, good resistance to abrasion, minimised slag formation with easy slag removal.
Thanks to its constant wire feed and excellent weldability, this wire is especially suited for automated welding.
Field of use: Cutting tools, esp. cutting edges of presses in ceramic tiles production, jaw crushers, baffle plates.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance Metal Cored UTP AF Robotic 352 FCAW - 1.6mm
Gas shielded metal-cored wire
Classification: 1430-B5Part No: BOH-ROBOTIC352-1.6-38736
UTP AF ROBOTIC 352 is a seamless, low-alloyed metal-cored wire for surfacing medium-hard steels. Thanks to its constant wire feed and excellent weldability, this flux-cored wire is especially suitable for automated welding.
Field of use: Pulleys, chains, crawler rollers and gear wheels.
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
UTP Maintenance Stick Electrode - UTP 68 HH Tig - 1.6mm 5Kg
Basic-coated NiCrFe stick electrode
Classification: E NiCrFe-3UTP 068 HH is predominantly used for joining identical or similar heat-resistant Ni-base alloys, heat-resistant austenites, such as 2.4817 (LC NiCr15Fe), 1.4876 (X10 NiCrTiAl 32 20), 1.4941 (X8 CrNTi 18 10). Specially used for joining of high carbon-containing 25/35 CrNi cast steel to 1.4859 or 1.4876 for petrochemical installations with working temperatures up to 900° C.
Furthermore, UTP 068 HH can be used for repair welding of hardly weldable steels such as heat-treatable steels or tool steels. Additionally mixed joints of austenitic and ferritic materials with elevated service temperatures can be welded.
The welding deposit of UTP 068 HH is hot-cracking-resistant, does not tend to embrittlement and is scale-resistant at high temperatures.
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
UTP Maintenance Stick Electrode - UTP 68 HH Tig - 2.4mm 5Kg
Basic-coated NiCrFe stick electrode
Classification: E NiCrFe-3UTP 068 HH is predominantly used for joining identical or similar heat-resistant Ni-base alloys, heat-resistant austenites, such as 2.4817 (LC NiCr15Fe), 1.4876 (X10 NiCrTiAl 32 20), 1.4941 (X8 CrNTi 18 10). Specially used for joining of high carbon-containing 25/35 CrNi cast steel to 1.4859 or 1.4876 for petrochemical installations with working temperatures up to 900° C.
Furthermore, UTP 068 HH can be used for repair welding of hardly weldable steels such as heat-treatable steels or tool steels. Additionally mixed joints of austenitic and ferritic materials with elevated service temperatures can be welded.
The welding deposit of UTP 068 HH is hot-cracking-resistant, does not tend to embrittlement and is scale-resistant at high temperatures.
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
UTP Maintenance Stick Electrode - UTP A 6222 Mo MMAW - 2.5mm 3.5Kg
Basic coated NiCrMo-stick electrode
Classification: ER NiCrMo-3UTP 6222 Mo is particularly suited for joining and surfacing on nickel alloys, austenitic steels, low-temperature nickel steels, austenitic-ferritic-joints and claddings of the same or similar nature, like 2.4856 (NiCr22Mo 9 Nb), 1.4876 (X30 NiCrAlTi 32 20), 1.4529 (X2 NiCrMoCu 25 20 5).
The weld metal is heat resistant and suitable for operating temperatures up to 1000° C. It must be noted that a slight decrease in ductility will occur if prolonged heat treatment is given within the temperature range 600 - 800° C.
Scale-resisting in the low-sulphur atmosphere up to 1100° C. High creep strength.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance Stick Electrode - UTP 776 Kb MMAW - 2.5mm 3.5Kg
Covered electrode
Classification: ENiCrMo-4Joint welding of matching base materials, as Material-No. 2.4819 (NiMo16Cr15W) and surfacing on low-alloyed steels. It is employed primarily for welding components in plants for chemical processes with highly corrosive media, but also for surfacing press tools, punches etc. which operate at high temperatures.
In addition to its exceptional resistance to contaminated mineral acids, chlorine contaminated media, and chloride containing media, it resists strong oxidisers such as ferric and cupric chlorides and is one of the few materials which will resist wet chlorine gas.
The stick electrode can be welded in all positions except vertical-down. Stable arc, easy slag removal.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance Stick Electrode - UTP 8 UTP 86 FN MMAW - 2.5mm 4.7Kg
Graphite-basic coated stick electrode Classification: ENi-Ci
UTP 8 is for cold welding of grey and malleable cast iron, cast steel and for joining these base metals to steel, copper and copper alloys, especially for repair and maintenance.
UTP 8 has excellent welding properties. The easily controllable flow permits spatter free welding in all positions and with minimal amperage. The weld deposit and the transition zones are fillable. No undercutting.
Ideally suited for the combined welding with the ferronickel type UTP 86 FN (buttering with UTP 8 and filling with UTP 86 FN).
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance Stick Electrode - UTP 7015 MMAW - 2.5mm 4.0Kg
Basic coated stick electrode
Classification: ENiCrFe-3UTP 7015 is employed for joining and surfacing of nickel-base materials. UTP 7015 is also recommended for welding different materials, such as austenitic to ferritic steels, as well as for weld claddings on unalloyed and low-alloyed steels, e. g. for reactor construction.
Weldable in all positions, except vertical down. Stable arc, good slag removability. The seam is finely rippled and notch-free. The weld deposit has a fully austenitic structure and is high temperature resistant. Not prone to embrittlement either at high or low temperatures.
The preheating must be matched to the parent metal. Any thermal post-treatments can be applied without regard for the weld metal.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance Stick Electrode - UTP 63 MMAW - 2.5mm 3.3Kg
Rutile coated, fully austenitic CrNiMnstick electrode
Classification: E 18 8 Mn R 32With the fully austenitic UTP 63, non-alloy structural and heat-treatable steels can be welded, also in combination with austenitic CrNi steels. Furthermore, scale-resisting steels for operating temperatures up to 850° C as well as higher carbon materials and high manganese steel can be joined, also in combination with other steels, with UTP 63.
For surfacing on workpieces exposed to impact, pressure and rolling wear, such as curved rails, points, crusher and excavator teeth. Moreover, it provides crack-proof buffer layers under hard alloys.
UTP 63 has good welding properties, stable arc, finely rippled bead appearance. The weld deposit resists to scaling, rust and cracks, work-hardened.
The hardness of the pure weld metal
Untreated: approx. 200 HB
Work-hardened: approx. 350 HB.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance Stick Electrode - UTP 65 MMAW - 2.5mm 3.0Kg
Rutile coated austenitic-ferritic special stick electrode with optimal welding and mechanical properties
Classification: E299R32UTP 65 is particularly suitable for joining on hardly weldable steels, when highest demands on the welding seam are made. High crack resistance when joining parent metals of difficult weldability, such as austenitic and ferritic steels, high-manganese steels with alloyed and non-alloyed steels, heat-treatable and tool steels.
As cushion layer on these materials it is also ideally suited. UTP 65 finds a variety of applications in the repair and maintenance of machine and drive components as well as in tool repairing.
UTP 65 is very easily weldable with a smooth and stable arc, homogeneous, finely rippled bead appearance and gives very good slag removal, self-lifting in parts. The austenitic ferritic weld deposit has highest strength values and high crack resistance. Stainless and work hardening.
Hardness of the pure weld metal: approx. 240 HB
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
UTP Maintenance Stick Electrode - UTP A 6222 Mo MMAW - 3.2mm 4.2Kg
Basic coated NiCrMo-stick electrode
Classification: ER NiCrMo-3UTP 6222 Mo is particularly suited for joining and surfacing on nickel alloys, austenitic steels, low-temperature nickel steels, austenitic-ferritic-joints and claddings of the same or similar nature, like 2.4856 (NiCr22Mo 9 Nb), 1.4876 (X30 NiCrAlTi 32 20), 1.4529 (X2 NiCrMoCu 25 20 5).
The weld metal is heat resistant and suitable for operating temperatures up to 1000° C. It must be noted that a slight decrease in ductility will occur if prolonged heat treatment is given within the temperature range 600 - 800° C.
Scale-resisting in the low-sulphur atmosphere up to 1100° C. High creep strength.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance Stick Electrode - UTP 776 Kb MMAW - 3.2mm 4.2Kg
Covered electrode
Classification: ENiCrMo-4Joint welding of matching base materials, as Material-No. 2.4819 (NiMo16Cr15W) and surfacing on low-alloyed steels. It is employed primarily for welding components in plants for chemical processes with highly corrosive media, but also for surfacing press tools, punches etc. which operate at high temperatures.
In addition to its exceptional resistance to contaminated mineral acids, chlorine contaminated media, and chloride containing media, it resists strong oxidisers such as ferric and cupric chlorides and is one of the few materials which will resist wet chlorine gas.
The stick electrode can be welded in all positions except vertical-down. Stable arc, easy slag removal.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance Stick Electrode - UTP 8 UTP 86 FN MMAW - 3.2mm 5.5Kg
Graphite-basic coated stick electrode Classification: ENi-Ci
UTP 8 is for cold welding of grey and malleable cast iron, cast steel and for joining these base metals to steel, copper and copper alloys, especially for repair and maintenance.
UTP 8 has excellent welding properties. The easily controllable flow permits spatter free welding in all positions and with minimal amperage. The weld deposit and the transition zones are fillable. No undercutting.
Ideally suited for the combined welding with the ferronickel type UTP 86 FN (buttering with UTP 8 and filling with UTP 86 FN).
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance Stick Electrode - UTP 7015 MMAW - 3.2mm 4.3Kg
Basic coated stick electrode
Classification: ENiCrFe-3UTP 7015 is employed for joining and surfacing of nickel-base materials. UTP 7015 is also recommended for welding different materials, such as austenitic to ferritic steels, as well as for weld claddings on unalloyed and low-alloyed steels, e. g. for reactor construction.
Weldable in all positions, except vertical down. Stable arc, good slag removability. The seam is finely rippled and notch-free. The weld deposit has a fully austenitic structure and is high temperature resistant. Not prone to embrittlement either at high or low temperatures.
The preheating must be matched to the parent metal. Any thermal post-treatments can be applied without regard for the weld metal.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance Stick Electrode - UTP 63 MMAW - 3.2mm 4.8Kg
Rutile coated, fully austenitic CrNiMnstick electrode
Classification: E 18 8 Mn R 32With the fully austenitic UTP 63, non-alloy structural and heat-treatable steels can be welded, also in combination with austenitic CrNi steels. Furthermore, scale-resisting steels for operating temperatures up to 850° C as well as higher carbon materials and high manganese steel can be joined, also in combination with other steels, with UTP 63.
For surfacing on workpieces exposed to impact, pressure and rolling wear, such as curved rails, points, crusher and excavator teeth. Moreover, it provides crack-proof buffer layers under hard alloys.
UTP 63 has good welding properties, stable arc, finely rippled bead appearance. The weld deposit resists to scaling, rust and cracks, work-hardened.
The hardness of the pure weld metal
Untreated: approx. 200 HB
Work-hardened: approx. 350 HB.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance Stick Electrode - UTP 65 MMAW - 3.2mm 4.5Kg
Rutile coated austenitic-ferritic special stick electrode with optimal welding and mechanical properties
Classification: E299R32UTP 65 is particularly suitable for joining on hardly weldable steels, when highest demands on the welding seam are made. High crack resistance when joining parent metals of difficult weldability, such as austenitic and ferritic steels, high-manganese steels with alloyed and non-alloyed steels, heat-treatable and tool steels.
As cushion layer on these materials it is also ideally suited. UTP 65 finds a variety of applications in the repair and maintenance of machine and drive components as well as in tool repairing.
UTP 65 is very easily weldable with a smooth and stable arc, homogeneous, finely rippled bead appearance and gives very good slag removal, self-lifting in parts. The austenitic ferritic weld deposit has highest strength values and high crack resistance. Stainless and work hardening.
Hardness of the pure weld metal: approx. 240 HB
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
UTP Maintenance TIG Rod - UTP A 387 GTAW - 1.6mm 5.0Kg
TIG Rod
Classification: ERCuNiUTP A 387 is used for copper-nickel alloys with up to 30 % nickel according to DIN 17664, such as CuNi20Fe (2.0878), CuNi30Fe (2.0882). Chemical industry, seawater desalination plants, shipbuilding, offshore technique.
The weld metal of UTP A 387 is resistant to seawater and cavitation.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance TIG Rod UTP A6222 Mo TIG 1.6mm 5.0Kg
Tig Rod Classification: ER NiCrMo-3
Part No: BOH-ERNiCrMo3-2.4-80436
UTP A 6222 Mo has a high nickel content and is suitable for welding high-strength and high corrosion resistant nickel-base alloys, e. g. X1 NiCrMoCuN25206 1.4529 UNS N08926 X1 NiCrMoCuN25205 1.4539 UNS N08904 NiCr21Mo 2.4858 UNS N08825 NiCr22Mo9Nb 2.4856 UNS N06625 It can be used for joining ferritic steel to austenitic steel as well as for surfacing on steel.
It is also possible to weld 9 % nickel steels using this wire due to its high yield strength. Its wide range of uses is of particular significance in aviation, in the chemical industry and in applications involving seawater.
The special features of the weld metal of UTP A 6222 Mo include a good creep rupture strength, corrosion resistance, resistance to stress and hot cracking. It is highly resistant and tough even at working temperatures up to 1100° C.
It has an extremely good fatigue resistance due to the alloying elements Mo and Nb in the NiCr-matrix. The weld metal is highly resistant to oxidation and is almost immune to stress corrosion cracking. It resists intergranular penetration without having been heat treated.
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
UTP Maintenance TIG Rod - UTP A 387 GTAW - 2.4mm 5.0Kg
TIG Rod
Classification: ERCuNiUTP A 387 is used for copper-nickel alloys with up to 30 % nickel according to DIN 17664, such as CuNi20Fe (2.0878), CuNi30Fe (2.0882). Chemical industry, seawater desalination plants, shipbuilding, offshore technique.
The weld metal of UTP A 387 is resistant to seawater and cavitation.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance TIG Rod UTP A6222 Mo TIG 2.4mm 5.0Kg
Tig Rod Classification: ER NiCrMo-3
Part No: BOH-ERNiCrMo3-2.4-80436
UTP A 6222 Mo has a high nickel content and is suitable for welding high-strength and high corrosion resistant nickel-base alloys, e. g. X1 NiCrMoCuN25206 1.4529 UNS N08926 X1 NiCrMoCuN25205 1.4539 UNS N08904 NiCr21Mo 2.4858 UNS N08825 NiCr22Mo9Nb 2.4856 UNS N06625 It can be used for joining ferritic steel to austenitic steel as well as for surfacing on steel.
It is also possible to weld 9 % nickel steels using this wire due to its high yield strength. Its wide range of uses is of particular significance in aviation, in the chemical industry and in applications involving seawater.
The special features of the weld metal of UTP A 6222 Mo include a good creep rupture strength, corrosion resistance, resistance to stress and hot cracking. It is highly resistant and tough even at working temperatures up to 1100° C.
It has an extremely good fatigue resistance due to the alloying elements Mo and Nb in the NiCr-matrix. The weld metal is highly resistant to oxidation and is almost immune to stress corrosion cracking. It resists intergranular penetration without having been heat treated.
For further information and best pricing - Please contact your local branch.Trade & Volume Pricing Available
UTP Maintenance TIG Rod UTP A6222 Mo TIG 2.4mm 5.0Kg
TIG Rod Classification: ER 312
Part No: BOH-ER312-2.4-37444
UTP A 651 is suitable for joining and surfacing of steels of difficult weldability, repair of hot and cold working steels, cushioning layers. The weld metal of UTP A 651 is scale resistant up to 1150° C. Crack and wear-resistant, stainless and work hardening.
The hardness of the pure weld metal: approx. 240 HB
For further information and best pricing - Please contact your local branch.
Trade & Volume Pricing Available
UTP Maintenance Flux Record 605. SAW Fluoride - Basic Type 25Kg Bag
UTP Record 605 Flux
SAW flux, fluoride-basic type, hard-facingClassification: SA FB 1 65 DC H5
Part No: BOH-REC605-PB25-36277
UTP RECORD 605 is an agglomerated flux for submerged arc welding. It is recommended for surfacing application especially with different unalloyed and low alloyed SAW wires. It has neutral metallurgical behaviour and provides excellent slag detachability even at high interpass temperatures. Suited for welding with single and multi-wire configurations.
The flux is mostly applied with solid and with flux-cored wires for hard-facing applications up to hardness up to 50HRC.
For further information and best pricing - Please contact your local branch.
